25 Pair 3m Compatible Module
Product Specifications
| Prod Model: |
AQ-SSM-25P |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Telephone |
| Type: |
Wired |
| Support Network: |
CDMA |
| Information Content: |
Data |
| Condition: |
New |
Product Description
Features:1.The Module contains self-stripping phosphor bronze U-contacts, wire channels, and stainless steel cut-off blades. It is used for two-wire splicing applications.
2.The Module accepts 0.65-0.32mm(22-28 AWG) solid copper conductors with PIC, pulp or paper insulation diameters 1.65mm(0.065") in the insulation displacement contact(IDC) at both ends of the element.
3.The length is 164.5mm (6.48"). The width is 15mm (0.59"). The crimp Height is 9.1mm (0.36").
4.All materials is suitable for operation in the tropic with maximum temperature up to 70oC.5.All materials used in the connectors shall be non-toxic and dermatologically safe.6.Moudle can retain the electrical & mechanical properties in the test report
over working temperature range -30oC to 70oC and humidity range of 0% to 85%.
7. Compatible for 3M modulesOur packing:
Ningbo Aqrich Co., Ltd. is a manufacturer, enjoys rich experience in communication and electronic field, together with good quality and excellent service we have won appreciation from global partners.
Our company supply: Subscriber Terminal Block Products (STB Distribution Box, 1 pair drop wire connection module. ), LSA-PLUS Compatible Products (10 Pair Disconnection Module, Protection Magazine, Distribution Box. ). Network Connector Products (RJ45 Cat5E Module, CAT6 Module, Faceplate, Patch Panel...), etc.
Our research department is matched with advanced computer assistant design system AutoCAD and completed inspection equipment. The equipment including: Dropping Test Table, Low & High Temperature Cabinet, Aging Testing Cabinet, Resistance Tester, Plating-thickness tester. And the tester equipment FLUKE DSP-4300 specially for networking products. etc.
We always keep tidy workshops, reasonable and compact production lines, and a group with professional trains, so as to guarantee the reliable products and efficient production. From design, raw material purchasing, craft, finished inspection to sales, our company carry out whole quality management system and insist on strict quality standard to satisfy the clients.
We have more than 20 corporation partners in Europe, America, MID-East and Asia. Our products are labeled famous brands and sold to all parts of the world. We appreciate to share success and happiness with all of you.
