| Price: | US $ 0.11/Meter |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 20000/Meter |
| Pay Type: | L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: | 2740 |
|---|---|
| Markets: | North America,South America,Africa,Mid East,Eastern Asia,Western Europe |
| Diameter: | 0.5-30mm |
| Package: | 50-100m/Roll,According to Clients'request |
| Thickness: | 0.5-20mm |
| Quality Warranty Period: | 6 Months |
| Application: | Switch Baseplate |
| Type: | Solid |
| Chemistry: | Inorganic Insulation |
| Material: | Resin |
| Thermal Rating: | F 155 |
| Maximum Voltage: | <10KV |
| Color: | Red,White,Black,Blue,etc. |
| Brand: | Chr |
Item | Unit | Normal value | |||
inner dia.& wall thickness(mm) | mm | inner dia(mm) | wall thickness(mm) | ||
standard | tolerance | min | max | ||
0.5-3.0 | ±0.20 | 0.45 | ±0.10 | ||
4.0-9.0 | ±0.25 | 0.55 | ±0.15 | ||
10-14 | ±0.50 | 0.70 | ±0.20 | ||
16-20 | ±1.00 | 0.90 | ±0.30 | ||
flame resistance | / | not less than 45 sec./25mm | |||
elasticity | / | no cracking or detachment of coating visible (1) after 3 hours at 200±2°C. (2) after 2 hours at -40±6°C | |||
breakdown voltage | kv.min | room temp. | 4.0 | ||
after damp | 2.0 | ||||
heat resistance | / | no cracking detachment of coating visible after 72 hours at 200±5°C | |||
quality warranty period | 6 months | ||||
