Product Specifications
| Prod Model: |
SPM-N |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Self-Adhesive Modified Bitumen Waterproof Material |
| Construction Method: |
Self Adhesive |
| Width: |
1m |
| Length: |
20m/15m |
| Size: |
1.2/1.5/2.0mm*20m/15m*1m |
| Surface: |
Aluminum Foil |
| Certificates: |
ISO;SGS;D&B Duns No.530910769 |
| Application: |
Exposed Roof of Civil&Industrial Project |
| Brand: |
Hongyuan/OEM/ODM |
| Package: |
Woven Bags+Cartons+Pallets |
| Type: |
Roofing and Waterproofing |
| Ceiling Tile Shape: |
Roll |
| Surface Treatment: |
Film Coated |
| Function: |
Waterproof |
| Certification: |
ISO |
| Color: |
Black |
| Thickness: |
1.2mm,1.5mm,2.0mm |
| Usage: |
Roofing & Underground.etc. |
Product Description
self-adhesive bitumen waterproof membrane for roof
1. Product Instruction:
Speed grams of self-adhesive polymer modified bitumen waterproofing membrane is as SBS synthetic rubber, high grade road asphalt and tackifier as base material, using polyester film (PET), polyethylene (PE) film, aluminum foil or coated silicon isolation membrane for the surface material, the lower surface coated with silicone coated isolation membrane for self-adhesive polymer anti sticking layer made of modified asphalt waterproofing membrane without tire.
2. Product's Performance:
1) Cold construction: no fire use, not suitable adhesive, energy saving, environmental protection, low carbon economy,
2) The bonding performance excellence, in viscoelastic state for a long time, to ensure the integrity of the waterproof layer;
3) Gao Yanshen performance, excellent shear strain;
4) Excellent low temperature performance;
3. Technical Specification:
| Item | Specification |
| Width(mm) | 1000/2000 |
| Thickness(mm) | 1.2/1.5/2.0 |
4. Application:
1) Waterproof non exposed roofing, underground engineering; waterproof drains, swimming pool and other municipal engineering;
2) Subway engineering waterproof method etc..
3) Especially in the waterproof engineering can not use open flame.
4) Excellent low temperature performance is more suitable for cold areas.
5. Technical Index:
China National Standard GB23441-2009
| No. | Item | PE film | D |
| Type | Type |
| 1 | Tensile properties | Tensile strength(N/50mm) ≥ | 150 | 200 | - |
| Elongation at Max. tensile strength % ≥ | 200 | - |
| Elongation at bitumen breaking % ≥ | 250 | 450 |
| Phenomenon when stretching | No bitumen coating cover layer and PE film separation phenomenon before PE film rupture | - |
| 2 | Nail tear resistance N ≥ | 60 | 110 | - |
| 3 | Heat resistance | 70ºC slippage less than 2mm |
| 4 | Low temperature resistance ºC | -20 | -30 | -20 |
| 5 | Watertightness 0.2Mpa,120min | No leakage | - |
| 6 | Peel strength between membranes N/mm ≥ | 1.0 |
| Peel strength between membrane and aluminum sheet. N/mm ≥ | 1.5 |
| 7 | Nail bar watertightness | pass |
| 8 | Oil permeability/sheets ≤ | 2 |
| 9 | Holding power/min ≥ | 20 |
| 10 | Heat aging test | Tensile strength retention % ≥ | 80 |
| Elongation at Max. tensile strength % ≥ | 200 | 400 ( Asphalt layer Elongation) |
| Low temperature resistance ºC | -18 | -28 | -18 |
| Peel strength between membrane and aluminum sheet N/mm ≥ | 1.5 |
| 11 | Heat stability | Appearance | No slipping, flowing or dripping |
| Dimensional Changes % ≤ | 2 |
| | | | | | | | |
