Shanghai Shisheng Machinery Manufacturing Co., Ltd. >> 3/4 MPa Fusheng Industrial Piston Air Compressor with Tank

3/4 MPa Fusheng Industrial Piston Air Compressor with Tank

Name: 3/4 MPa Fusheng Industrial Piston Air Compressor with Tank
Brand: china-manufacturer-directory.com
SKU: 771612675
Availability: InStock
Rating: 4.9 (136 reviews)

Supplier:	Shanghai Shisheng Machinery Manufacturing Co., Ltd.
Price:	US $ 1400-8000set
Min Order:	1set
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	SSH-10030
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Piston Reciprocating
Working Pressure:	30bar
Air Delivery Rate:	1m3/Min
Power Source:	AC Power
Lubrication Style:	Oil Ubricated

Product Description

Our medium pressure compressor is applied to industries as PET bottle blowing, air leak test, pressure test etc. our compressor can run 24h/7d continually and is applied in various kind of environments with their higher efficiency and reliability, longer lifetime, lower energy cost and low outlet temperature, which is designed for medium and high pressure applications. The main technical data has reached to European level.
Valve plate: made from Sweden SS
Piston ring: monomer cast piston rings, lifetime 3 times
Piston: boosting piston is cast by heavy duty cast iron
Connecting rod: connecting rod with needle bearing
Crankshaft: heavy duty, low noise, long lifetime
Block cooling fan wheel: moving balance iron wheel fan to reduce vibration
Pressure controller: imported renowned brand
Cooling & filtration: high efficiency cooling and filtration from 1^st to 2^nd stage, 2^nd stage low temperature and clean
Drain: auto electric drain (option)

3Mpa piston air compressor

Model	SSH-6030	SSH-8030	SSH-10030	SSH-12030	SSH-16030	SSH-20030	SSH-30030
Block type	PISTON	PISTON	PISTON	PISTON	PISTON	PISTON	PISTON
Volume(m³/min)	0.6	0.8	1.0	1.2	1.6	2.0	3.0
W.Pressure(Mpa)	3.0	3.0	3.0	3.0	3.0	3.0	3.0
RPM(r/min)	830	800	780	780	830	830	780
Lubrication	splash	splash	splash	splash	splash	splash	splash
drive	belt	belt	belt	belt	belt	belt	belt
cooling	Air cooling	Air cooling	Air cooling	Air cooling	Air cooling	Air cooling	Air cooling
Motor power(Kw)	7.5	7.5	11	15	18.5	2X11	30
Power source(v/Hz)	380/50	380/50	380/50	380/50	380/50	380/50	380/50
noise(dB (A))	≤72	≤72	≤78	≤78	≤85	≤85	≤85
Cylinders diameter(mm)	2X¢95 ¢55	2X¢100 ¢55	2X¢120 ¢65	2X¢120 ¢65	2X¢135 ¢120 ¢65	4X¢120 2X¢55	¢210 ¢120 ¢100
size(mm)	1470(L) 530(W) 1020(H)	1490(L) 600(W) 1160(H)	1550(L) 730(W) 1280(H)	1620(L) 730(W) 1280(H)	1900(L) 850(W) 1600(H)	1900(L) 900(W) 1400(H)	1850(L) 1000(W) 1100(H)
weight(Kg)	290	430	480	520	600	600	1150

4Mpa piston air compressor

Model	SSH-8040	SSH-12040	SSH-16040	SSH-20040	SSH-30040	SSH-6060	SSH-12060
Block type	PISTON	PISTON	PISTON	PISTON	PISTON	PISTON	PISTON
Volume(m³/min)	0.8	1.2	1.6	1.8	3.0	0.6	1.2
W.Pressure(Mpa)	4.0	4.0	4.0	4.0	4.0	6.0	6.0
RPM(r/min)	780	800	780	780	850	780	780
Lubrication	splash	splash	splash	splash	splash	splash	splash
drive	belt	belt	belt	belt	belt	belt	belt
cooling	Air cooling	Air cooling	Air cooling	Air cooling	Air cooling	Air cooling	Air cooling
Motor power(Kw)	11	18.5	18.5	22	30	15	22
Power source(v/Hz)	380/50	380/50	380/50	380/50	380/50	380/50	380/50
noise(dB (A))	≤85	≤85	≤85	≤85	≤85	≤85	≤85
Cylinders diameter(mm)	¢125 ¢95+¢36 ¢65	¢160 ¢100 ¢65	2X¢135 ¢100 ¢55	2X¢120 2X¢55	¢210 ¢120 ¢100	¢125 ¢95+¢34 ¢65	2X¢130 ¢80 ¢42
size(mm)	1650(L) 730(W) 1150(H)	1900(L) 850(W) 1600(H)	1750(L) 750(W) 1100(H)	1900(L) 950(W) 1400(H)	1950 (L) 1000 (W) 1100(H)	1650(L) 730(W) 1150(H)	1700 (L) 850(W) 1300(H)
weight(Kg)	550	560	600	600	1150	550	600

WOOD PACKING

Shanghai Shisheng Machinery Manufacturing Co., Ltd was founded in 1993. We have more than 20 experienced technicians to design, manufacture, and maintain compressors, and we supplied compressors to a wide range of industrial applications at home and abroad, which is petro-chemical, oil, communication, medicine, food, plastics, army, and power station.

We manufacture a comprehensive compressors up to 35MPa, we supply medium pressure air compressor, high pressure air compressor, air cooling screw compressor, water cooling screw compressor, booster compressor, high precision filter, dryer etc, we can supply a completely system to supply clean and stable air source for your applications
