3 Axles Low Bed Semi Trailer (CLW9400)
Product Specifications
| Prod Model: |
CLW9400 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Clw9400 Van Series Trailer |
| Dimension: |
12990* 2500*2250mm |
| Tyre Soecification: |
11.00-20 |
| G. V. W: |
39600kg |
| Load . W: |
31700kg |
| N. W: |
7900kg |
| Practicality Load: |
30000-5000(Kg) |
| Wheel Span: |
7200+1310+1310 |
| Tyre Span: |
1840 |
| F/B(Suspend): |
-/2070mm |
| Type: |
Semi-Trailer |
| Material: |
Steel |
| Scale: |
Heavy Duty |
| Certification: |
SGS |
| Components: |
Trailer Axles |
| Load Capacity: |
30T |
Product Description
Detailed description:
1 The semi-trailer flat-panel truck also called the flatbed trailer, semitrailer engineering machinery vehicles. Usually use the Au beam (or well-type) frame, The front segment of the frame into the gooseneck(The gooseneck preceding's kingpins is connected with the traction saddle on tracto, the back-end of the gooseneck is connected with the semi-trailer frame). The middle is the Goods table(The lowest part of the frame). Back-end is round frame(Contains the wheel). Loading machinery and equipment to the semi-trailer engineering machinery vehicles. It's usually loaded from the back-end of the semi-trailer machinery and equipment.
2 When loading machinery and equipment to the low flatbed semi-trailer. Usually loaded machinery and equipment from the semi-trailer back-end. So use of mobile mechanical equipment or remove the wheels from the top of the rear wheel frame, and then fixed in the semi-trailer on machinery and equipment.
3 The main platform of the frame cargo is low. To ensure the smooth transport, suitable for carrying all kinds of engineering machinery, large equipment, and steel. Using three-axis balanced, double axis balanced or rigid suspension, equipped with a mass balance blocks between the front and rear leaf springs, It can make the front and rear leaf spring deflection same amount of change. So that the front and rear axle force balance. Low flatbed semi-trailer series products are widely used in a variety of mechanical equipment, large objects, road construction equipment, large tanks, the transport of power plant equipment, machine steel, widely used, effective and efficient. The whole truck uses advanced computer-aided design software to optimize the design of flexible frame bearing surface, to meet a variety of special cargo transport designed according to user requirements.
Item |
units |
parameter |
Product name |
|
CLW9400 van series trailer |
dimension |
mm |
12990× 2500× 2250 |
Tyre soecification |
|
11.00-20 |
|
|
G. V. W |
kg |
39600 |
|
|
Load . w |
|
31700 |
|
|
N. W |
|
7900 |
|
|
Practicality load |
|
30000-5000(kg) |
|
|
Wheel span |
|
7200+1310+1310 |
|
|
|
Tyre span |
|
1840 |
|
|
Approach/departure angle |
° |
- / 14 |
F/B(suspend) |
mm |
-/2070 |
