3-in-1 Automatic Carbonated Beverage Botting Machine
This DCGF Carbonated beverage wash-filling-sealing 3-in-1filling machine used to produce PET bottled carbonated beverages (soda) production, such as Coca-Cola, Fenda, Sprite and gas-bearing mineral water.
Characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; Canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. The cylinder drive the valve the movements is accurate and reliable. High-throughput, high-precision filling valve, filling fast and accurate. Equipped the CIP loop and control procedures, the equipment is easy to clean.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
|
Model |
Number of washing filling and capping |
Production capacity
Bottle per hour(0.5L) |
Applicable bottle specifications (mm) |
Power(kw) |
Dimension(mm) |
|
DCGF14/12/5 |
14, 12, 5 |
2000-3000 |
0.25L-2L
50-108 mm
H=170-340mm |
3.58 |
2100x1400x2500 |
|
DCGF18/18/6 |
18, 18, 6 |
4000-6000 |
4.68 |
2460x1720x2650 |
|
DCGF24/24/8 |
24, 24, 8 |
6000-8000 |
6.58 |
3100x2100x2650 |
|
DCGF32/32/8 |
32, 32, 8 |
10000-12000 |
9.68 |
3500x2500x2650 |
|
DCGF40/40/10 |
40, 40, 10 |
13000-15000 |
|
9.68 |
4600x1800x2650 |
|
DCGF50/50/12 |
50, 50, 12 |
16000-18000 |
10.8 |
5200x4500x3400 |
|
DCGF60/60/15 |
60, 60, 15 |
20000-22000 |
11.28 |
6500x4500x3400 |
Zhangjiagang Beverage Machinery Co., Ltd was founded in Sept., 1994. Our company is located in Leyu Economic Development Zone of Zhangjiagang City, about 180km from Shanghai Pudong International Airport (Google Position), convenient transportation; Company covers an area of about 4, 000 square meters, with more than 60 employees, We are mainly engaged in manufacturing the bottling and packaging equipments of various liquid food and beverage. Company integrates machine design, making, sales and after sales service.
Our products scope as below:
PET bottle filling machine
Water filling machine
Juice filling machine
Beverage filling machine
Soft drink filling machine
Alcohol filling machine
Oil filling machine
Other bottle filling machine
Labeling machine, wrap packing machine, water treatment system, and some auxiliarys.
We gained rich experience on carbonated drink, juice beverage, as well as glass bottle beverage, alcohol etc. filling technology, and own several patented technologies. In China, we have many customers in almost every province and city, and has a good reputation in. Currently, near 40% of our orders from our registered customers, that's the reason we still remain stable development even in the downturn global economic.
We began to run our own export business from 2010, machines have been exported to American, Canada, Bolivia, Chile, Columbia, Guatemala, Russia, Britain, Slovakia, Sri Lanka, Indonesia, Cambodia, Malaysia, Algeria, Egypt, Zambia, South Africa and other countries.
We'll supply you professional suggestion, good quality machines and professional services, to push our clients to create the greatest economic benefits.
We are trying to do better in this field, also sincerely hope that we could build good cooperation relations with more beverage manufacturers.
Services we provided:
Free technical consultation, Investment budget;
Customized high-quality equipment, Whole Production Plant layout;
Comprehensive after-sales service, Machine installation and Commissioning, training workers to learn how to operate and maintain the equipment, supply customers needed accessories in time.
