Hyrite Lighting Co. >> 350mA 10W Triac PWM Switching Power Supply Dimmable

350mA 10W Triac PWM Switching Power Supply Dimmable

Name: 350mA 10W Triac PWM Switching Power Supply Dimmable
Brand: china-manufacturer-directory.com
SKU: 728248065
Availability: InStock
Rating: 4.3 (136 reviews)

Supplier:	Hyrite Lighting Co.
Price:	US $ 5.80-6.10/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	SD-350E10
Markets:	North America,South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Power:	10W
Output:	Constant Current or Constant Voltage
Input Voltage:	170-250V
IP Rating:	IP20 Non Waterproof
Warranty:	2 Years Warranty
Use:	for Spot Light, Down Light, Panel Light
Size:	1154527mm
Case:	Plastic
Usage:	Construction, Building
Circuit Structure:	PWM Controlled
Output Type:	Terminal
Driving Method:	Constant Voltage or Constant Current
Certification:	CE, EMC, SAA
Power Supply Voltage:	AC220-240V
Brand:	Neonpro

Product Description

350mA 10W Dimmable LED driver with Ce

Features:
Constant current output ,IP20

Leading or trailing edge dimming, 10%-100% no flickering

Used for LED Module, Strip, Spot Light, Down Light, Panel Light ect

Protection: Over Load, Over Heat, Short Circuit

Data sheet:

Model no.	SCD-350E10
Input voltage	170-250 VAC 50/60 Hz
Max. power	10W max
Dimmer	TRIAC Dimmer
Output type	Constant Current
Efficiency	85%
Output	350mA
Overload protection	105% hiccup mode, auto-recovery
Over voltage protection	120% rated output voltage
Withstand voltage	I/P~O/P:1.5kVAC, 1 minute
Operating temperature	-25~40 degree
Installation	Non Waterproof
IP rating	IP20
Certificates/standards	CE
Connection input/output	Terminal
Dimensions(LWH)	1154527 mm
Packing information	100Pcs/ Carton, G.W 13KG

More about Hyrite:

Hyrite Lighting Company, also known as NeonPro Co, has 20 years experience in the design, development and manufacturing of electronic power supplies, one of an extremely successful range of signage products including, over the last seven years, LED modules and driver units.

The senior management having recognized the ongoing success and further potential of our LED products and utilizing their experience and proven track record in innovative product design and manufacture has formed Hyrite Lighting Company solely dedicated to manufacturing products specifically for the LED signage and lighitng markets.

Our products are surrently being used in many countries under different technical standards in a variety of climate conditions.

Pls kindly check our main products below,

*IP67 Slim high efficiency constant voltage LED power supply (New)

*Traditional IP67 constant voltage waterproof LED power supply

*IP45 Rainproof constant voltage LED power supply.

*IP20 indoor type LED power supply.

*Constant Current LED Driver for LED lighting.

*Dimmable LED driver.

*LED module for Channel letter/light box.

Certificate: CE RoHS SASO SAA TUV UL approved

In addition we offer comprehensive OEM and ODM services to our partners.

We sincerely welcome your visiting and valued advices to us. Any questions from you, our experienced salesperson will feedback to you within 12 hours.
