3600-450 Fourdriner Single Cylinder Toilet Paper Making Machine
Product Specifications
| Prod Model: |
3600-450 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output Paper: |
Toilet Paper, Napkin Paper, Facial Tissue etc Bas |
| Basis Weight: |
15-45GSM |
| Trim Width: |
3600mm |
| Working Speed: |
450m/Min |
| Drive Speed: |
500mm |
| Dynamic Balancing Speed: |
600m/Min |
| Gauge: |
4800mm |
| Drive Type: |
AC Variable Frequency Division Control |
| Main Drive Power: |
509kw |
| Outline Dimension: |
About 32m*10m*8m (L*W*H) |
| Sheet Former Type: |
Fourdrinier Wire |
| Paper Thickness: |
Normal Specification Paper |
| Certification: |
UL |
| Condition: |
New |
| Type: |
Toilet Paper Machine |
Product Description
This machine is mainly composed of Headbox, fourdriner wire, MG dry section , calender, drive section and reeling end etc.
The papermaking process is as follows: the paper pulp through the square taper duct into Headbox, in the fourdriner section forming and preliminary hydro-extraction. Move the wet paper adsorption in felt with the vacuum suction. Through the first double-felt groove pressed, with the felt into between the first Dryer and touch roller, close to the cylinder surface drying, crinkle. Finally through the reel machine to batching.
More details please contact with Tel:+8618265537767
Shandong XinHe Paper-Making Engineering Co., Ltd is located in Liaocheng, west of Shandong province, which is a beautiful Water-City in the north of China. We are a professional integrated company. Main business includes paper machine manufacturing, engineering installation, commissioning and the total package of paper-making project. We own a group of excellent staff team and powerful, high-precise processing and welding equipments. Since the company was established, it has served dozens of production lines for many paper-making enterprises and enjoys a good reputation among them. A number of mills have contracted more than 10 production lines. The company is also equipped with a large number of the entire production line and assembly parts mainly exported to Southeast Asia, West Asia and South America etc.
Comer S. P. A. Was founded in 1960, is locate in Vicenza of Italy famous architecture city. It has long been engaged in mechanical pulp production line, deinked pulp production line, high-speed tissue machine, head box and designing and production of Yankee dryer. Several tissue machines in America, Brazil, Saudi Arabia etc had functioned very well, the machine speed is more than 1200m/min(basis weight 13G/m2), with low energy consumption. The finished paper has high flexibility. Comer S. P. A has first-rate design team, advanced processing equipment, pulp preparation system and pulp research lab.
Now Comer S. P. A. Authorized our company as sole agent of Crescent Tissue Machine in China. AP and South America which the paper width is between 2800-5000mm, the speed is or more than 1200-2000m/min, sell kinds of head box, steel Yankee dryer, suction touch roll, doctor and pulp-making equipments etc.
We will supply high quality product, lab service, field installation and training for all paper mills. We want to bring max profit for our customer with high quality product and low price.
