3G network feature
1, support multi-network operation, HSUPA, HSDPA, WCDMA, EDGE, GPRS, GSM
2, support 7.2Mbps download and 5.76Mbps upload in HSUPA network
3, support HSPA/UMTS 850/1900/2100MHz frequency and quad-band GPRS/GSM network
4, support roam technology in both 3G and 2G networks
5, support auto register in mobile networks
6, support 3.0V USIM card
Ethernet and WLAN feature
1, support 10/100Mbps auto negotiation Ethernet RJ45 port
2, support MIDX RJ45 connection
3, support DHCP server mode
4, support dynamic and static routing
5, support 802.11 b, 802.11g, 802.11n draft WIFI
6, support 300Mbps WLAN transmission
7, support 2.4GHz~2.485GHz WIFI frequency
8, support WPA, WPA-PSK, WPA2, WPA2-PSK, WPAPSK/WPA2PSK, WPA1WPA2, 802.1X, AES/STIK WIFI encryption way
9, support auto transfer WIFI channel
10, support WDS, WPS, and AP client
11, support on line clients up to 32 users
12, support PPPOE, DHCP / fixed IP wired Internet
13, support PPTP, L2TP VPN pass through
Hardware Interface and Electronic features
1, USIM slot *1, RJ45 LAN *4, RJ45 WAN*1, USB port *1
2, Fixed external 3G antennas, WIFI antennas
3, 3G, Ethernet, WLAN, Power led indication
4, support reset key and WPS key
5, support power range DC9V~36V
6, support over-voltage, over-current protect
7, support ESD up to 3KV
8, working temperature -10º C~ 50º C, storage temperature -20º C~60º C
9, 400 MHz MIPS® 24K™ CPU core
10, 64M flash, 256M SDRAM
Firmware features
1, support inbuilt firewall with MAC/IP/Port/Content filter
2, support port forwarding and DMZ
3, support system commands
4, support firmware update via local LAN connection
5, support web management and web update
6, support IE 6.0, firefox 1.0 and higher versions
7, support English, Chinese web management
8, support modification on user name and password
9, support NTP on power
10, support DDNS account list
11, support bridge, gateway and AP client mode
12, support NAT and TCP/UDP ping setting
13, support FTP server and USB DISK share
14, support back up settings
There's a leading manufacturer MOBDIATA in China, specialized in designing, manufacturing, marking GPRS, UMTS, EVDO, HSPA, LTE, WIMAX wireless terminals covering industrial PCI/RS232/USB wireless modem, industrial class 3G/4G wireless router, Home/office 3G/4G WiFi wireless router for nearly 8 years.
Our products is widely use in areas of video transmission, M2M application, security system, monitoring system, kiosk 3G, industrial PC, industrial router, VoIP system, tel communication system and so on. The mission of our company has always been to focus on perfect Internet terminals.
With the yearly designing experience, professional technical supports, qualified production and assembling line, powerful manufacturing capability, excellent oversea marketing capability, Since establishment in 2004 year. Mobidata is popular with our end uses, wholesalers, distributors, partners over the world.
Good quality, good service have been favoring our development. However with the advantage of experienced engineers we are confidential to meet the new challenge, and provider more creative productions to our customers.
So far we have the belowing production solutions available for market.
1, Wireless solution SOHO network
GPRS USB wireless modem
EDGE USB wireless modem
HSDPA USB wireless modem
HSUPA USB wireless modem
Pocket 3G WiFi wireless router
4 ports 3G HSUPA WiFi wireless router
4 ports 3G HSUPA WiFi wireless router
4 ports 4G LTE WiFi wireless router
2, Wireless solution for Kiosk
Windows, Linux, WinCE 3G HSDPA USB modem
Windows, Linux, WinCE 3G HSUPA USB modem
Windows, Linux, EDGE, GPRS USB Modem
3G HSDPA PCI wireless modem
3G HSDPA PCI wireless modem
RS232 GPRS GSM wireless modem
RS232 EDGE GPRS wireless modem
3, Wireless solution for video transmission
Ethernet RJ45 3G HSUPA router
Ethernet RJ45 3G EVDO router
Ethernet RJ45 4G LTE router
Ethernet 3G HSUPA WiFi wireless router
Ethernet 3G EVDO WiFi wireless router
Ethernet 4G LTE WiFi wireless router
