Product Specifications
Prod Model: |
SD-A013 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Size: |
L92*W92*H45 |
Cut Off Dimension: |
D75mm |
LED Chip Brand: |
Bridgelux, Citizen, Epistar |
Power: |
3W |
Certificates: |
EMC, RoHS, CE, LVD, C-Tick, SAA, CCC |
CRI: |
80 |
Lumen: |
500+/-10% |
Warranty: |
2 Years |
Certification: |
VDE |
Beam Angle: |
25?? |
Style: |
modern |
Shape: |
Square |
Shade Type: |
Acrylic |
Lamp Body Material: |
Aluminum |
IP Rating: |
IP20 |
Install Style: |
Recessed |
Color Temperature: |
2700k-6500k |
Usage: |
Commercail,Resident |
Voltage: |
AC85-265V |
Product Description
3W high quality competitive price square led down light with CE/ROHS
1) AC85-265V input voltage
2) CE, RoHS SAA certificates
3) Lifespan: 50, 000hrs
4) 2 years warranty
Advantage:
1) 5 -10 years of life (6 hours per day)
2) unique optical design, no light pollution, glare-free, uniform light field, no strobe
3) above 95% lamp efficiency
4) above 80% power efficiency, power factor greater than 0.85l
5) color rendering index greater than 80, good color performance, close to natural light
6) 3000K-7000K wide range color temperature
7) isolated low-voltage constant current driver, security, stability, reliability
8) green, lead-free, no UV radiation, no breakable glass
9) significant energy savings, saving more than 90% saving rate compared to conventional tungsten incandescent lamps, more than 70% compared to fluorescent lights.
Descriptions:
Model No.: SD-A013
Description: 3W LED ceiling light
LED Chip brand: Bridgelux/Epistar/Samsung
Input Voltage: AC 85-240V
Light Efficiency: ≥ 115LM/W
Lumens: 345 LM
LED Driver: PFC>0.92, Power Efficiency > 0.88
CRI: 75-85
Material: Aluminum+Glass
Instrallation Way: Recessed
Drilling hole: 75mm
Beam Angle: 30/45/60/90/120 degree
Frequency: 50/60 Hz
Working Environment: -30° C— +65° C
Life time>50, 000 hours
Protection Grade: IP20
CCT: 2800-7000K
Warranty: 2 years
LED ceiling light Application:
1. Recessed lighting, shelf lighting, ceiling/wall cover
2. Cabinet and under counter lighting, office ect.
3. Back lighting, step lighting, light boxes
4. Merchandising, exhibition stands, and panels
Factory Information:
Our Factory was located in Zhongshan Guzhen, the Lightings center, and We have 4 production lines, and with more than 100 workers. Our products has got CE, RoHS, EMC, LVD, FCC, SAA, C-TICK, and widely sell to European markets, Australia Market, Newsland market, Russia, etc...
We Promise that:
Our products are 100% go through materials in-coming inspection, on-line inspection, more than 24hrs life test!
100% ON-LINE life test
Test machines
Customers with US:
Choose us, Choose the High quality products!
Model |
Power |
Luminous flux |
Input voltage |
CCT |
Hole size |
Appearance size |
Shell material |
Packing quantity |
SD-A011 |
1*1W*1 |
90lm/w |
AC85-265V |
2700K-6500K |
D50mm |
L60*W60*H25mm |
Pure aluminum |
60PCS |
SD-A021 |
1*1W*2 |
90lm/w |
AC85-265V |
2700K-6500K |
L105*W50mm |
L125*W60*H25mm |
Pure aluminum |
48PCS |
SD-A031 |
1*1W*3 |
90lm/w |
AC85-265V |
2700K-6500K |
L165*W50mm |
L180*W60*H25mm |
Pure aluminum |
24PCS |
SD-A041 |
1*1W*4 |
90lm/w |
AC85-265V |
2700K-6500K |
L105*W105mm |
L125*W125*H25mm |
Pure aluminum |
36PCS |
SD-A013 |
3*1W*1 |
90lm/w |
AC85-265V |
2700K-6500K |
D75mm |
L92*W92*H45mm |
Pure aluminum |
60PCS |
SD-A023 |
3*1W*2 |
90lm/w |
AC85-265V |
2700K-6500K |
L160*W75mm |
L175*W92*H45mm |
Pure aluminum |
24PCS |
SD-A033 |
3*1W*3 |
90lm/w |
AC85-265V |
2700K-6500K |
L235*W75mm |
L250*W92*H45mm |
Pure aluminum |
12PCS |
SD-A043 |
3*1W*4 |
90lm/w |
AC85-265V |
2700K-6500K |
L160*W160mm |
L177*W177*H45mm |
Pure aluminum |
12PCS |
SD-A015 |
5*1W*1 |
90lm/w |
AC85-265V |
2700K-6500K |
D95mm |
L115*W115*H70mm |
Pure aluminum |
48PCS |
SD-A025 |
5*1W*2 |
90lm/w |
AC85-265V |
2700K-6500K |
L205*W95mm |
L230*W115*H70mm |
Pure aluminum |
24PCS |
SD-A035 |
5*1W*3 |
90lm/w |
AC85-265V |
2700K-6500K |
L270*W95mm |
L330*W115*70mm |
Pure aluminum |
12PCS |
SD-A045 |
5*1W*4 |
90lm/w |
AC85-265V |
2700K-6500K |
L205*W205mm |
L230*W230*H70mm |
Pure aluminum |
12PCS |
SD-A017 |
7*1W*1 |
90lm/w |
AC85-265V |
2700K-6500K |
D95mm |
L115*W115*H70mm |
Pure aluminum |
48PCS |
SD-A027 |
7*1W*2 |
90lm/w |
AC85-265V |
2700K-6500K |
L205*W95mm |
L230*W115*H70mm |
Pure aluminum |
24PCS |
SD-A037 |
7*1W*3 |
90lm/w |
AC85-265V |
2700K-6500K |
L270*W95mm |
L330*W115*H70mm |
Pure aluminum |
12PCS |
SD-A047 |
7*1W*4 |
90lm/w |
AC85-265V |
2700K-6500K |
L205*W205mm |
L230*W230*H70mm |
Pure aluminum |
12PCS |
