4 Cells Li-ion Battery Charger with UL/cUL, CE, GS, SAA, PSE (16.8V3A, FY1703000)
Product Specifications
| Prod Model: |
FY1703000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimenision: |
133*58*31mm |
| Weight: |
0.4kg |
| Warranty: |
3 Years |
| Lead Time: |
18 Days |
| Type: |
Lithium Battery |
| Charger Type: |
Electric Charger |
| Certification: |
GS,SAA, FCC,CCC |
| Socket Type: |
Us, UK, EU, Au, PSE, |
Product Description
Features/Functions
Reverse polarity protection
Sensing and following battery voltage
Constant charging current
Stopping charge once battery is full
with a dual color LED indicator
Safety standard approvals: UL, cUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick
General Specifications
| Input | 100-240VAC, 50/60Hz |
| Output voltage | 16.8VDC |
| Output current | 3A +/-0.3A |
| Inrush current | Limited 30A for a cold start |
| No load standby power | ≤ 0.5W |
| Efficiency | 85% Min. |
| Operating temperature | -29ºC~+45.5ºC |
| Storage temperature | -40ºC~+75ºC |
| Operating relative humidity | 5%~95% RH |
| Over load protection | Auto recovery |
| Over voltage protection | Auto recovery |
| Short circuit protection | Auto recovery |
| MTBF | 30000 hours full rated load operation at 25ºC |
| Inspection | MIL-STD-105D II AQL: CRI 0; MAJ 0.25; NIN 2.5 |
| Package | White box in carton |
| Lead time | 18 days |
| Samples | Yes |
Fuyuan Electronic Co., Ltd is a professional manufacturer of switching power supplies and battery chargers. Relying on our engineer team with more than 25 years' experience in the field, we focus on designing and manufacturing switch mode chargers and power adapters of high efficiency and environmental protection. We are in the leading position of making Lead-acid, Li-ion and Ni-MH battery chargers and LED drivers.
Our battery chargers have the following functions
1, Reverse polarity protection
2, Sensing and following the battery voltage
3, Constant output current
4, Overheat protection design
5, Lower output voltage once charge completed
6, Two-color LED indicates working state
We have over 460 models with different specifications ranging from 0.9W to 120W (output voltage: 3V-58V and output current: 300mA- 7500mA). All products meet the RoHS standard, and have been approved by UL, cUL/CSA, TUV/GS, CE, BS, SAA, EK, PSE, CB, CCC, FCC, and EMC. Our products are widely used not only in charging lead-acid, Li-ion and Ni-MH batteries, such as the batteries for electric vehicles and battery operated toys, but also in powering massagers, medical equipments, monitor systems, instruments and meters, car or home appliances, LCD screens, LED lights, and telecommunication equipments.
We follow the international standards of the quality control system to provide our customers with high quality products. Whatever you need about our products, you can always expect to find the best products from us very quickly.
