4 Color Flexo Graphic Printing Machine (CH884)

Name: 4 Color Flexo Graphic Printing Machine (CH884)
Brand: china-manufacturer-directory.com
SKU: 686635025
Availability: InStock
Rating: 5 (119 reviews)

Supplier:	Rui'an Changhong Printing Machinery Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Set
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	CH884
Markets:	North America,Mid East,Eastern Asia,Western Europe
Printing Material:	Plastic Film, Plastic Bag
Anilox Roller:	Metal Anilox Roller
Printing Roll Lift System:	by Hydrulic
Tension Controller:	Auto Tension for Unwind and Rewind
EPC For Unwind:	Edge Position Controller
Register Color:	by Manual
Color & Page:	Multi-Colour Printing Press
Plate:	Relief Printing
Embossing Structure:	Rotary Letterpress
Printing Speed:	30-80m/Min

Product Description

4 Color Flexo graphic Printing Machine (CH884)

The main features:
1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for group control.
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.
7. Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8. With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll

Printing width Item	600mm	800mm	1000mm	1200mm	1400mm	1600mm	1800mm	2000mm
Printing color	PC:4+0;3+1;2+2
Printing length	7.5"-40"/7.5"-50"/7.5"-60"/7.5"-70"/7.5"-80"
Printing plate lifting system	Pneumatic/Hydraulic press control/Menu
Mechanical speed	90m/min
Printing speed	70m/min
Anilox cylinder	Metal: 10DK-120DK(Germany)
Register precision	Longitude:±0.25mm Transverse:±0.25mm
Rewinder/Unwinder DIA	ø 600mm
Master motor	3.0KW	3.0KW	3.7KW	3.7KW	5.5KW	5.5KW	7.5KW	7.5KW
Unwinder motor	1.1 KW		1.5 KW		2.2 KW		3.0 KW
Rewinder motor	1.5 KW		2.2 KW		3.0 KW		3.7KW
Electrical header	14KW	16KW	20KW	22KW	24KW	26KW	28KW	30KW
Blower of header	1.5KW×2	1.1KW×3	1.1KW×3	1.1KW×3	1.5KW×3	1.5Kw×3	2.2KW×3	2.2KW×3
Blower of nature wind	0.75 KW	0.75 KW	1.1 KW	1.1 KW	1.1 KW	1.5KW	1.5KW	1.5KW
Inking motor	750W	750W	750W	750W	750W	750W	750W	750W
Master frequency converter	transducer Japan
Bearing	Japan(NSK)
Unilateral bearing	ASNU (Germany)
Weight	3500Kg	3750Kg	4000Kg	4250 Kg	4500Kg	4750Kg	5000Kg	5300Kg
Master power	20KW	22KW	26KW	28KW	34KW	37KW	45KW	48KW
Dimension (L×W×H)	4.5m × 1.8m × 2.5m	4.5m × 2.0m × 2.5m	4.5m × 2.2m × 26m	4.5m × 2.4m × 2.6m	4.5m × 2.6m × 2.7m	4.5m × 2.8m × 2.7m	4.5m × 3.0m × 2.7m	4.5m × 3.2m × 2.7m

Located in Ruian, Zhejiang, Ruian Changhong Machinery Factory is a manufacturer of printing machinery which specializes in the production of flexographic printing machines.

Over the years, we have been sticking to the enterprise concept that the management of an enterprise is the management of talents. Every staff member takes "customer satisfaction as the supremacy. with our confidence and ceaseless efforts, we firmly believe that our enterprise will have a more splendid future!

Changhong Machinery Factory is mainly engaged in design and manufacturing of printing machines. At present, with the Project Department, the Technical Service Department and the New Product Research Center which all boast tremendous strength, it is capable of independently developing new flexographic printing machines. Machinery products developed in the recent years, such as high-speed computerized chromatic flexo printing machines, high-speed cascading flexo printing machines and in-line flexo printing machines, are exported to various regions and countries including Eastern Europe, North America, South America, Southeast Asia, Russia, Africa, Middle East, etc., which have received good market feedback and positive comments from customers.

The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
