4 Color High Speed Paper Roll/Cup Printing Machine (CH884)

Name: 4 Color High Speed Paper Roll/Cup Printing Machine (CH884)
Brand: china-manufacturer-directory.com
SKU: 691207305
Availability: InStock
Rating: 4.9 (131 reviews)

Supplier:	Rui'an Changhong Printing Machinery Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Set
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	CH884
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Printing Material:	Paper, Roll Paper
Anilox Roller:	Metal Anilox Roller
Printing Roller Lift System:	by Hydrulic
Tension For Unwind And Rewind:	Auto Tension Controller
EPC For Unwind:	Edge Position Controller
Register Color:	by Manual
Color & Page:	Multi-Colour Printing Press
Structure:	Rotary Letterpress
Plate:	Relief Printing
Model:	Stack Type Flexo Printing Machine
Printing Speed:	30-80m/Min

Product Description

4 Color Flexo Film Printing Machine
The main features:
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7. Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8. With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Prrint produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll

Printing width Item	600mm	800mm	1000mm	1200mm	1400mm	1600mm	1800mm	2000mm
Printing material	Single adhesive paper, Double adhesive paper, Copper plate paper, Kraft paper: 50-180g/m² , Single filter membrance paper, Double filter membrance paper: 80-300g/m²
Printing color	4 special color
Material feeding width	700mm	900mm	1100mm	1300mm	1500mm	1700mm	1900mm	2100mm
Printing length	7.5" -40" : 90mm-1016mm; 7.5" -50" : 90mm-1270mm; 7.5" -60" : 90mm-1524mm;
Printing plate lifting system	Pneumatic/Hydraulic press control
Mechanical speed	90m/min
Printing speed	10-80m/min
Anilox cylinder	80DK-170DK(Germany)/180LPI-800LPI
Register precision	Longitude: ± 0.1mm Transverse: ± 0.1mm
Rewinder/Unwinder DIA	ø 1000mm /ø 1200mm /ø 1500mm
Master motor	5.5W		7.5KW		11W		15KW
Rewinder motor	5.5KW				7.5KW
Unwinder motor	5.5KW				7.5KW
Electrical header	26KW		32KW		38KW		45KW
Blower of header	0.75KW		1.1 KW W		1.5 K W		2.2 K W
Blower of nature wind	0.75 KW		1.1 KW		1.5 KW		2.2 KW
Inking motor	370W				750W
Master frequency converter	5.5KW		7.5KW		11KW		15 KW
Master power	45KW		54KW		68KW		82KW
Weight	8100Kg	g8760Kg	9300 Kg	9750 Kg	10120Kg	10500Kg	11000Kg	11700Kg

Located in Ruian, Zhejiang, Ruian Changhong Machinery Factory is a manufacturer of printing machinery which specializes in the production of flexographic printing machines.

Over the years, we have been sticking to the enterprise concept that the management of an enterprise is the management of talents. Every staff member takes "customer satisfaction as the supremacy. with our confidence and ceaseless efforts, we firmly believe that our enterprise will have a more splendid future!

Changhong Machinery Factory is mainly engaged in design and manufacturing of printing machines. At present, with the Project Department, the Technical Service Department and the New Product Research Center which all boast tremendous strength, it is capable of independently developing new flexographic printing machines. Machinery products developed in the recent years, such as high-speed computerized chromatic flexo printing machines, high-speed cascading flexo printing machines and in-line flexo printing machines, are exported to various regions and countries including Eastern Europe, North America, South America, Southeast Asia, Russia, Africa, Middle East, etc., which have received good market feedback and positive comments from customers.

The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
