Product Specifications
| Prod Model: |
K04002 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Layer: |
4 L |
| Thickness: |
1.6mm |
| Copper Finished: |
1oz |
| Surface Treatment: |
Immersion Gold |
| Solder Mask: |
Green |
| Printed Circuit Board: |
Four Layers |
| Main Chipset: |
Intel |
| Structure: |
ATX |
| SATA Interface: |
SATA2.0 |
| Audio Effects: |
HiFi |
| Memory: |
DDR2 |
| Integrated Graphics: |
Integrated Graphics |
| CPU Socket: |
LGA 775 |
| Maximum Memory Capacity: |
8G |
| Main Board Structure: |
Integrated |
Product Description
E-SOURCES Three Advantages
1) Integrate Industry chain, we have 3 our own and holding companies for manufacturing components and PCBs. We can do PCBA, ODM, OEM and EMS one stop service, can ensure high quality and low price.
2) Professional, we have imported and advanced WORLD FAMOUS BRAND producing and inspection equipment. We have 10 experienced engineers to keep our process and technology support, we have our own corporation culture and management system ISO9001:2008 to courage our stuffs high efficiency.
3) Excellent Service, our experienced engineers and advanced equipments can control the producing, inspection and after service to satisfy our customers need, and our dedicate sales team can provide 24 hours service.
| Process/Spec. | E-SOURCES | Machine Feature | Normal Company |
| Print | Japan SUNEAST | high-precision, high-stable | local machine |
| SPI | Korea KOHYOUNG 3D SPI machine | high-reliable, high-precision | No SPI |
| SMT | Fuji AIMEX-2; SAMSUNG SM481,421,411 placement equipment | SM421:high-flexible SM481:High-speed, high-flexible AIMEX-2: High-speed(4-robot,dual lane), high-flexible | local machine |
| Solder | U.S. HELLER,BTU,German REHM reflow owen | high-precision, high-stable | local machine |
| DIP | automatic manual DIP | Praticed workers | automatic manual DIP |
| AOI | Japan OMRON online and offline AOI machine | high-reliable, high-precision | local machine |
| Package | ESD | strict process system | ESD |
| Component suppliers | Long time strategy partners with world-class component suppliers. | stable and low prices | Often changes component suppliers. Quality is unstable. |
| Warehouse | Constant temperature, dustproof, moistureproof, anti-static. | ensure the quality | Common Warehouse. |
FAQ
Q1: What is your products range?
We provide PCBA for IT, communication, tablet PCs, smart cards, financial equipments, auto electronics, GPS modules. We can do OEM,ODM.
Q2:Do you provide material sourcing service?
We have our own industry chain. Our material sources are stable, high quality and low prices.
Q3:What is you trade term?
FOB Guangzhou/Shenzhen port.
Q4: How do you make sure product quality?
We have 3D SPI, AOI,and we do ICT, Electronic test, Visual inspection, Functional test.
