Elite Optoelectronics Co., Ltd. >> 405nm to 980nm with Different Output Power Industrial Laser Diode Module

405nm to 980nm with Different Output Power Industrial Laser Diode Module

Name: 405nm to 980nm with Different Output Power Industrial Laser Diode Module
Brand: china-manufacturer-directory.com
SKU: 711357935
Availability: InStock
Rating: 4.7 (136 reviews)

Supplier:	Elite Optoelectronics Co., Ltd.
Price:	Negotiable/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wavelength:	405nm-980nm
Beam Type:	DOT, Line.Cross
Delivery Time:	20days Accroding to Your Quantity
Manufacturing Technology:	Optoelectronic Semiconductor
Type:	P-type Semiconductor
Material:	Alunimium Anodized or Brass
Package:	Customized

Product Description

Detailed Product Description

Industrial laser diode module
Customized design
Reliability and stability up to 98% +
ISO9001: 2008; SGS; FDA
DOT, line, cros

405nm to 980nm with different output power Industrial laser diode modules

Key Feature
1. High quality
2. High Stability
3. High reliability
4. APC driving circuit
5. Low cost
6. Long Life

Application:
Industrial Instruments and Equipments
Wild Explore Instruments
Military Instruments and Equipments
Medical Instruments
Surveying Instruments
Bar Scan

Items	Specifications
Spectral Range	Violet	Blue	Red		Infrared
Wavelength	405nm	450nm	635nm	650nm	780nm	808nm	830nm	850nm	980nm
LD power(mW)	5- 50	5-60	5~180	5~150	5~200	50~5000	5-100	5~100	20~5000
Operating Current	25~5000mA
Input Voltage	2.6~5.5VDC
Operating Temp.	-10°C ~ 50°C
Storage Temp.	-40°C ~ 80°C
Power Stability	> 98% (@2.7 ~ 5.5VDC)
	> 95% (@-10°C ~ 50°C)
MTTF	>10000 Hrs.
Circuit Protection	Static, Surge, and Reverse Polarity Protected
Case Material	Brass or Aluminum
Beam Pattern	Dot, Line ,Cross

Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.

Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.

Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.

Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
