Product Specifications
| Prod Model: |
EL405D10IG1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Laser Sight: |
Violet |
| Wavelength: |
405nm |
| Lifetime: |
>10, 000hrs |
| Delivery Time: |
10-20day Depending on The |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1, ClassIIIa
2, mini violet laser diode module
3, wide operate tem.
4, FDA ISO. etc
5, Industrial level quality
405nm Violet Laser Module EL405D10IG1
Features
Wavelength: 405 nm
High brightness, optical output power: 1.0 mW
Low operating current: < 55mA
Low operating voltage: 6VDC
Class IIIa laser, CDRH/RoHS compatible
Static, Surge, and Reverse Polarity Protected
Circuit control: Auto power control (APC)
Operating Temperature: -10 to 50° C.
|
Parameter |
Symbol |
Ratings |
Unit |
|
Optical Output Power |
P0 |
< 1.0 |
mW |
|
Operating Temperature |
Topr |
-10 to +50 |
° C |
|
Storage Temperature |
Tstg |
- 40 to +80 |
° C |
|
Operating Humidity (none condensing) |
RHopr |
90 |
% |
Optical and Electrical Characteristics
|
Parameter |
Specifications |
Test Conditions |
|
Wavelength |
405 nm |
Tc = 25° C |
|
Output Power |
< 1.0mw |
Tc = 25° C |
|
Laser Modes |
CW |
|
|
Output Aperture |
4.5 mm |
Factory fixed |
|
Beam Size |
< 5 mm |
Factory fixed @ 10m |
|
|
< 12 mm |
Factory fixed @ 30m |
|
Divergence |
0.1 mrad |
Tc = 25 ± 3° C |
|
Optics |
Glass lens |
|
|
Operating Current |
< 55mA |
Tc = 25± 3° C |
|
Operating Voltage |
5 VDC |
|
|
CDRH Class |
Class II |
|
|
MTTF |
10000 Hrs |
Tc = 25± 3° C |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
