0.45um 0.6MPa Cartridge Pool Filter Powder Removal Security Filter

0.45um 0.6Mpa Cartridge Pool Filter Powder Removal Security Filter


 Working principle

1,Precision filtration is to adopt the molding of filtration material, under the action of the pressure filtration material, make prefiltration through, stay in wall, phosphate-contained residue filtrate through filtering material flow, so as to achieve the purpose of filter.

2,Filtration material molding of filter cloth and filter are:, filter slice, sintering filter tubes, wire wound filter, melt-spurt filter core, etc. Because of the different filtration material, filtration aperture is not identical also. Precision filtration was between sand filter (coarse filter) and ultrafiltration between filtering, filtration aperture in commonly 0.5 ~ 120 mu m range. The same form of filtration material, press envelop dimensions can be divided into different specifications.

3,Wire wound filter (also called hive filter) has two kinds: one kind is polypropylene fibre - polypropylene skeleton cores, highest use temperature 60 °C; Another kind is absorbent cotton fiber - stainless steel frame filter, the highest temperature. Use 120 °C

4,Melt-spurt polypropylene filter is for raw material, adopting melt-spurt technology shaping filter material, the maximum operating temperature 60 °C. Precision filter can remove the water the suspended material and fine, certain colloid particles, etc.

Product characteristic

1.Material and structure
cylindrical shells, 304 or 316L stainless steel,
 match with single or multivessel filter,
 customers can request the qualitative customized processing.

2. Model
1 shell material: 304, 316L stainless steel, carbon steel and optional resin shell,
l filter quantity: 1, 2, 3 core core core... ;
l cartridge length: single section, second quarter, three, four day (every 10 "for the section),
l filter installation forms: international general flat crush type, card into the type and plug-in,
l cylinder and base way.this way: quick open type (Q), flange type (F);
l medium inlet and outlet connections: quick open type (Q), thread type (S) and flange type (F);
Can filter medium: liquid (L), gas (G).

3.Performance characteristics
(1) filtering precision, filter aperture evenly.
(2) filter small resistance and flux big, cut corrupt capability is strong, long service life.
(3) filter materials for spotlessness, filter medium pollution-free.
(4) in acid or alkali chemical solvents.
(5) strength, high temperature resistant, filter is out of shape not easily.
(6) cheap, low operating cost, easy cleaning, filter replaceable.

 4.Application scope
1).nanofiltration (NF), ultrafiltration (UF), RO (RO), electrodialysis (EDI) system security filtration and terminal filter,
2).medicine injection, big transfusion, eye drops, Chinese herbal medicine, biological agents such as filtering liquor extraction, purification and concentration,
3).electronics, microelectronics, semiconductor industry with high pure water filtration, advance the terminal filtration,
4).oilfield waterflooding, back to the boiler make-up water, chemical reagent, liquid organic products, high purity chemicals, strong medicine such as filtering,
5).drinking pure water, mineral water, juice, tea beverages, health drink filtering,
6).liquor, wine, beer, yellow wine and other ratafia filtering, pure draft beer aseptic filtration (replacing pasteurising);
7).production and living in wastewater treatment and water recycling process of pretreatment filter or security filtering,
8 ).and other such as biological engineering, oil refining, printing and dyeing, textile industry of water and wastewater treatment, scientific experiment filtration and so on.

Specifications:

model	diameter	Nos. and length of  pp filter cartridge	wall thickness	capacity	water inlet-outlet
			mm	m³/hour	mm
YL3-10	Φ167	3 cartridges 10 inch	1.5	1	DN25
YL3-20	Φ167	3 cartridges 20inch	1.5	1.5	DN25
YL5-10	Φ219	5 cartridges 10inch	1.5	1.5	DN25
YL5-20	Φ219	5 cartridges 20inch	1.5	3	DN25
YL5-30	Φ219	5 cartridges 30inch	1.5	5	DN32
YL5-40	Φ219	5 cartridges 40inch	1.5	7	DN40
YL7-20	Φ219	7 cartridges 20inch	1.5	5	DN32-40
YL7-30	Φ219	7 cartridges 30inch	1.5	7	DN32-40
YL7-40	Φ219	7 cartridges 40inch	1.5	10	DN40-50
YL10-40	Φ300	10 cartridges 40inch	2	15	DN50-65
YL15-40	Φ350	15 cartridges 40inch	2	25	DN65
YL20-40	Φ400	20 cartridges 40inch	2	35	DN80
YL25-40	Φ450	25 cartridges 40inch	2.5	45	DN100
YL30-40	Φ500	30 cartridges 40inch	3	55	DN100
YL35-40	Φ550	35 cartridges 40inch	3	65	DN125
YL45-40	Φ600	45 cartridges 40inch	3	75	DN125
YL50-40	Φ650	50 cartridges 40inch	3	80	DN125-150
YL60-40	Φ700	60 cartridges 40inch	3	100	DN150
YL65-40	Φ750	65 cartridges 40inch	3	120	DN150
YL70-40	Φ800	70 cartridges 40inch	3	120	DN150
YL80-40	Φ900	80 cartridges 40inch	4	140-160	DN150
YL100-40	Φ1000	100 cartridges 40inch	4	180-200	DN150


 FAQ:

01. What is the capacity (m3/hour) you required for this equipment?
02. What is the working pressure?
03. What is the filtration degree?
   1 micron or other?
