4pgc Series Four Teeth Roll Crusher (090810)

Name: 4pgc Series Four Teeth Roll Crusher (090810)
Brand: china-manufacturer-directory.com
SKU: 702348742
Availability: InStock
Rating: 4.3 (103 reviews)

Supplier:	Weifang Better Heavy Machinery Science and Technology Co., Ltd.
Price:	US $ 5000/Set
Min Order:	1/Set
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	090810
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Motor Type:	AC Motor
Condition:	New
Motor Power:	45kw 55kw
Application:	Mining,Coal, Chemical, Electric Power,
Materials:	Coal,Gangue,Slag,Coke,Limstone,Finesandstone,

Product Description

Four teeth roll crusher with high efficiency,energy saving ,intelligent and so on ,mainly applied compressive strength values ≤80Mpa ,particle size ≤300mm of materials such as coal ,gangue ,slag ,coke and other crushing ,crushing directly to 10mm less (above 90%).it has a crushing large capacity unit ,small energy consumption ,widely used and so on .manly used in electric power ,mining ,coal ,chemical and other industrial sectors ,is a circulating fluidized bed boiler plants,coking plants,steel mills crushed coal is one of the best.

Features
High yield ,uniform particle size ,particle size of 10~15mm range crushing adjustable
Two rolls or air swirl basic offset each other ,equipment import and export of wind pressure is extremely small ,basic does not generate dust,do not install adedicated dust removal equipment
Using a special movement principle the device does not block non-stick ,no requirement for crushing material moisture.
A significant reduction in vibration and noise (no damping platform ),dynamic load is only 1.3times the static load of the building has little effect
Includes a special opening device can easily open the device's door for easy access to replacement of wearing parts

The main technical parameters

Model	Feeding (mm)	Discharging (mm)	Capacity (t/h)	Motor		Weight (t/h)	LWH (mm)		DZG
Model	Feeding (mm)	Discharging (mm)	Capacity (t/h)	Motor		Weight (t/h)	A	B	Motor power (kw)
070608	≤300	≤8	50	Y250M-6N=45KW	Y280S-6N=45KW	10160	370014501730	370031001730	0.4
080709			70	Y250M-6N=37KW	Y280S-6N=45KW	13890	376015501930	376032001900	0.8
090810			90	Y280S-6N=45KW	Y280M-6N=55KW	15680	390017602130	390055002130	0.8
090910			120	Y280M-6N=55KW	Y315S-6N=75KW	19000	417619382140	461439342340	1.5
100811			140	Y280M-6N=55KW	Y315S-6N=75KW	21000	461418242340	461439342340	0.8
100911			170	Y315S-6N=90KW	Y315L1-6N=110W	25320	495219242340	495241942340	1.5
101111			200	Y315M-6N=90KW	Y315L1-6N=110KW	25960	515222002360	515245402360	1.5
101311			250	Y315L1-6N=110KW	Y315L2-6N=132KW	27800	555224002360	555247402360	3
101411			300	Y315L2-6N=132KW	Y355M-6N=160KW	31680	490032262421	490049602421	3
101611			350	Y355M-6N=160KW	Y315M-6N=185KW	34680	490026212570	490026212570	4.4
101812			450	Y355M-6N=185KW	Y355L-6N=220KW	36860	515028142760	515047602760	4.4
101912			500	Y355L-6N=220KW	Y355L-6N=250KW	38200	655031002760	555047602760	4.4
102212			600	Y355L-6N=250KW	Y4002-6N=280KW	41200	515034002660	515042002660	7.4
102512			700	Y4002-6N=280KW	Y4003-6N=315KW	46780	515040002760	555067692560	7.4
102812			800	Y4003-6N=315KW	Y4OO4-6N=355KW	52860	515025002560	515042002560	11
113214			1000	Y4005-6N=400KW	Y4501-6N=450KW	55160	565030003080	565086003800	11
