5.8g Directional Panel Antenna for 22dBi (ARW-5725-5850-22)

5.8g Directional Panel Antenna for 22dBi (ARW-5725-5850-22)
Supplier: Shenzhen Arronna Telecom Co., Ltd.
Price: Negotiable/Piece
Min Order: 50/Piece
Quantity::
Trade Terms: FOB
contact supplier

Product Specifications

Prod Model: ARW-5725-5850-22
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color: White
Feature: High Gain
Usage: Communication Antenna
Directionality: Directional Antenna
Operating Wavelength: Medium Wave
VSWR: <1.5
Material: Al

Product Description

Low VSWR
Frequency range: 5725-5850MHz
Gain: 22dBi
Dimension: 306X306X20mm

Electrical Specifications



ARW-5725-5850-22

Frequency Range

5725-5850MHz

VSWR

≤2.0

Input Impedance

50Ω

Gain

22dBi

PolARization

Vertical or Horizontal

Horizontal Plane ΘHP

8°±1°

Vertical Plane ΘHP

8°±1°

BeAR Electrical Downtilt


Front to Back Ratio

≥30dB

Maximum Input Power

20W

Connector Type

N –Female

Intermodulation IM3

≤-107dBm

Lightning Protection

DC ground

Mechanical Specifications

Dimension

306mm×306mm×20mm

Weight

1.5kg

Rated Wind Velocity

210km/h

Radome material

UV protected ABS

DiAReter of installation pole

φ30-φ54mm

Working Temperature

-40~+60°C
Shenzhen Arronna Telecom Co., Ltd. was founded in 2007, mainly offer antenna OEM & ODM service for clients, mainly sector antenna, panel antenna, yagi antenna, fiberglass omni antenna at MIMO / LTE / WIMAX / WiFi / 3G / DECT / WLAN/ CDMA antennas. Shenzhen Arronna Antennas Co., Limited is an integrated high-tech company owning strong ability on R&D, production and selling. Welcome you to learn more about us.

Now ARRONNA owns more than 3, 000 square meters production area, about 80 staff (tech dept 6people, QC 6, the 40% staff has college background), 6 production line, more than 100 types of products covering frequency from 88MHz to 5.8GHz and these products has covered the following field such as WiFi / WIMAX wireless communication system, wireless data transmitting system, global position system, digital TV system and civil use. Now our products already work with 3G Telecom System, WiFi/WiMAX Telecom System, HUAWEI CPE and successfully worked with China MOBILE, GLOBE TELECOM and defeated many competitors to enter EU market, South-east Asia market and Asian Market.

Since founded, ARRONNA has developed fast by the clients' support! We strictly follow ISO9001: 2008 quality system to improve the architect and management style, and also use ISO14001: 2004 system to regulate and arrange production process. If we promise, you have my word! That is ARRONNA's motto! Hereby, ARRONNA sincerely welcome you visit our factory and give us your precious opinion, ARRONNA look forward to working with you soon!
