Price: | US $ 70000-114700/Piece |
---|---|
Trade Terms: | FOB,CFR,EXW |
Min Order: | 1/Piece |
Pay Type: | L/C,T/T |
MJK-5ASeries | MJK-13255A-ATC |
Table Area | 1450*2950mm |
X,Y,Z,A,A axis Working Area | 1300*2500*900*±245degree*±120 degree |
Table surface | Vacuum,T-slot |
Frame | Heavy steel |
XY structure | Rack and pinion drive.Hinwwin Rail Linear Bearing. |
Z structure | Hinwin Rail Linear ball screw. |
Traveling Positioning Accuracy | ±0.03/300mm |
Repositioning Accuracy | ±0.03/300mm |
Spindle Power | 15KW |
Spindle Speed | 24000rpm/min |
Drive Motors | Yaskawa Servo motor-1.8KW |
Working Voltage | AC380V/50HZ//3PH |
Operating system | OSAI control |
Software | Type3,Artcam,UG,MasterCam,Visual Mill |
Optional | Mist-cooling system, Rotary system,Partition table/Vacuum pump,Dust collecter |
Firstly, packed the cnc router machine with plastic sheet for clearing and damp proofing.
Secondly, then put the cnc router machine in the plywood case for safety and clashing.
Thirdly, transport the plywood case into the container.
For standard machines, it would be 7-10 wording days;
For non-standard and customized machines according to client's specific requirements, it would be 15-30 working days.
FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
8:Why choose Magiccnc company product?
1.Magiccnc product is widely used in almost all the materials which you can think of.
2.Magiccnc company is specialized in cnc router and laser machine manufacturing and selling. There is no middle man and no agent, so the price is best.
3.With high precision and high reputation is the most reliable goods you can choose.
4.Magiccnc company has all kinds machines in store, the delivery time is much shorter than other companies.
5.Magiccnc company has international tech service office and provides 24 hours online service.
9:Contact us
Prod Model: | MJK-1325-5A |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Model No: | Mjk-1325-5A |
Working Area: | 1300*2500*400*245 Degree*120 Degree |
Table Surface: | Vacuum, T-Slot |
Guide Rail: | Japanese THK/Taiwan Hiwin |
Driving System: | Yaskawa/Delta Servo Driver and Motor |
Spindle: | Italy Hsd Spindle |
Inverter: | Delta |
Control System: | Syntec/Osai |
Software: | Ug, Master Cam, Art Cam, Visual Mill, Type3f |
Warrantly: | 1 Year |
Spindle Layout: | Spindle Over |
Spindle Number: | Single-Spindle |
Feed Mode: | Mechanical |
Controlling Mode: | CNC |
Certification: | CE |
