| Price: | US $ 0.13-0.15/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 3000/Piece |
| Pay Type: | L/C,T/T,Western Union |
| Prod Model: | WD05013-A/B/AEG |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Western Europe |
| Digit Heiht: | 0.5 Inch |
| Ref Color: | Black or Gray |
| LEDs Color Options: | Red, Yellow, Blue, Green, White |
| LEDs Configuration: | Ca or Cc Available |
| LED Chips: | Epistar |
| Waterproof: | Not Waterproof |
| Emitting Color: | Red |
| IP Rating: | IP50 |
| 1 LED Power: | <0.3W |
| LED Light Source: | LED Chip |
| Power: | <0.3W |
About Fivelake Elec
Hangzhou Fivelake Electronics Co.,Ltd is a leading manufacturer of alpha numeric LED display module and LED display in China East. It's established in 1997 by a group of professionals who are the earliest people dealing with semiconductor business in Hangzhou, China. Due to the business extension and corporation size enlarging, we are divided into two companies for offering better service to our customers, one is Hangzhou Fivelake Electronics Co.,Ltd and the other is Hangzhou Newlake Electronics Co.,Ltd, both are owned by the same administrative team. Fivelake is specialized in LED alpha numeric display field while Newlake is specialized in big LED display such as bus LED display, LED moving display.
What We Do
> 7 Segment, 14 Segment, 16 segment LED Display
> LED Matrix
> LED Bus Display
> Gas Price LED Sign
Why Choose US
> We are the one of originated company of China LED council.
> We have been in design and production of LED related products for over 16 year, with abundant experience in this field.
> A dedicated and professional team will be your backup on hardware construction, software integration, a whole solution will be offered to you according to your application purpose.
> Strict checkout process is able to ensure quality products completed with no defect.
> Our products have exported to most Countries in the world, including Eroupe, America, Southeast Asia and Africa. We have built a long term business relationship with a France company who distributes our crossing LED display and oil pricing display in Europe since 2006.
> We are always developing new technology and new products to meet the exact requirement of clientele both domestic and abroad.
*****Free To Contact Us Now!*****
| Parameter | Symbol | Maximum Rating | Unit |
| Power Dissipation | Pd | 38 | mW |
| Peak Forward Current | Ifp | 60 | mA |
| Continuous Forward Current( Forward )Current | Ifm | 30 | mA |
| Reverse Voltage | VR | 5 | V |
| Operating Temperature Range | Topr | -20→ +80 | °C |
| Storage Temperature Range | Tstg | -20→ +80 | °C |
| Static Voltage | Var | 500 | V |
| Lead Solder temperature | 260°C for3 seconds | |
