Product Specifications
| Prod Model: |
GLM-005D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wavelength: |
532nm |
| Operate Temperature Range: |
-10°c~50°c |
| Life Span: |
> 8, 000hrs |
| Delivery Time: |
10-20day Depending on The |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
Detailed Product Description
- 5mW output power
- CDRH CLASS: CLASS IIIb
- High quality and stability
- High Reliability>98%
- Wide Operating temperatur
532nm 5mW green laser module GLM-005D
About us
We are a leading manufacturer specialized in designing and manufacturing different kinds of bore sighter and laser sighter in China with experience of more than 10 years, manufacturing according to ISO9001: 2008 quality control system guidline. All of our products are FDA certified and OEM service offered.
Description
The GLM-005D is a green laser subassembly with collimated beam. The maximum laser output power is 5.0 mW at532nm.
Features
Wavelength: 532 nm
High brightness, optical output power: <5.0 mW
Low operating current: <180mA
Low operating voltage: 3VDC
Class IIIa laser, CDRH/RoHS compatible
Static, Surge, and Reverse Polarity Protected
Circuit control: Auto power control (APC)
Operating Temperature: 0 to 45° C
Parameter |
Specifications. |
Test Conditions |
Wavelength |
532 nm |
Tc = 25° C |
Output Power |
4 ± 0.8mw |
Tc = 25° C |
Laser Modes |
CW |
|
Transverse mode |
TEM00 |
|
Output Aperture |
< 1.5 mm |
Factory fixed |
Beam Size |
< 8 mm |
Factory fixed @ 10m |
Divergence |
< 0.8 mrad |
Tc = 25 ± 3° C |
Stability |
> 80 % |
|
Operating Current |
< 180 mA |
Tc = 25± 3° C |
Operating Voltage |
3 VDC |
|
Operating Temp. |
0° C ~ 45° C |
|
Storage Temp. |
-20° C ~ 70° C |
|
Optics |
Glass Lens |
|
CDRH Class |
Class IIIa |
|
MTTF |
8000 Hrs. |
Tc = 25± 3° C |
Mechanical Characteristics
Parameter |
Specifications |
Dimensions |
8 x 28mm (without PCB) |
Case Material |
Brass |
Vibration |
DIN EN 60068-2-6 Standard |
Shock |
DIN EN 60068-2-29 Standard |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
