Elite Optoelectronics Co., Ltd. >> 532nm Laser Module Wide Temperature Range (GLM-005D)

532nm Laser Module Wide Temperature Range (GLM-005D)

Name: 532nm Laser Module Wide Temperature Range (GLM-005D)
Brand: China-Manufacturer-Directory.com
SKU: 708024975
Availability: InStock
Rating: 4.8 (139 reviews)

Supplier:	Elite Optoelectronics Co., Ltd.
Price:	Negotiable/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	GLM-005D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wavelength:	532nm
Operate Temperature Range:	-10°c~50°c
Life Span:	> 8, 000hrs
Delivery Time:	10-20day Depending on The
Manufacturing Technology:	Optoelectronic Semiconductor
Material:	Element Semiconductor
Type:	P-type Semiconductor
Package:	Customized

Product Description

- 5mW output power
- CDRH CLASS: CLASS IIIb
- High quality and stability
- High Reliability>98%
- Wide Operating temperatur

532nm laser module GLM-005D
Description
The GLM-005D is a green laser subassembly with collimated beam. The maximum laser output power is 5.0 mW at532nm.
Features
Wavelength: 532 nm
High brightness, optical output power: <5.0 mW
Low operating current: <180mA
Low operating voltage: 3VDC
Class IIIa laser, CDRH/RoHS compatible
Static, Surge, and Reverse Polarity Protected
Circuit control: Auto power control (APC)
Operating Temperature: 0 to 45° C.

Parameter	Specifications.	Test Conditions
Wavelength	532 nm	T_c = 25° C
Output Power	4 ± 0.8mw	T_c = 25° C
Laser Modes	CW
Transverse mode	TEM₀₀
Output Aperture	< 1.5 mm	Factory fixed
Beam Size	< 8 mm	Factory fixed @ 10m
Divergence	< 0.8 mrad	T_c = 25 ± 3° C
Stability	> 80 %
Operating Current	< 180 mA	T_c = 25± 3° C
Operating Voltage	3 VDC
Operating Temp.	0° C ~ 45° C
Storage Temp.	-20° C ~ 70° C
Optics	Glass Lens
CDRH Class	Class IIIa
MTTF	8000 Hrs.	T_c = 25± 3° C

Mechanical Characteristics

Parameter	Specifications
Dimensions	8 x 28mm (without PCB)
Case Material	Brass
Vibration	DIN EN 60068-2-6 Standard
Shock	DIN EN 60068-2-29 Standard

Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.

Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.

Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.

Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
