Sharpvision Co., Ltd. >> 5inch Wired Car Rear View System Wiht Auto Shutter Camera

5inch Wired Car Rear View System Wiht Auto Shutter Camera

Name: 5inch Wired Car Rear View System Wiht Auto Shutter Camera
Brand: china-manufacturer-directory.com
SKU: 682467132
Availability: InStock
Rating: 4.6 (71 reviews)

Supplier:	Sharpvision Co., Ltd.
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	MO-714D, CW-656
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Monitoring System
Technology:	Infrared
Kind:	Autofocus Lens
Feature:	Waterproof / Weatherproof
Sensor:	CCD
Horizontal Resolution:	480tvl
Application:	Rear View System

Product Description

5 inches 16: 9 digital rear view monitor for car Features:

Thin and small, 24.7mm thickness

Wide voltage input: Support 12V or 24V system

Power supply for camera, easy installation

Normal buttons and support remote control function

Backlighting for screen: Automatic backlighting when in dim light longer than 5s (Lighting brightness can be set up

And saved)

Picture image may be adjusted for horizontal or vertical viewing

Auto scan; The scanning function of each channel can be set up to turn on and off separately, scan time (time for

Switching to another channel) can be adjusted from 1 to 90S

Distance label can be turned on or off and adjusted up and down, left and right

Specification:

Shatterproof standard: 2.83G
Working condition: Performs in rugged conditions; Operating temperature: -20º C~70º C
TV system: PAL/NTSC/AUTO
Language system: 8 languages selectable
Video input: 13PIN: Support 3 audio inputs
Distance label: Can be adjusted up and down, left and right.
Auto trigger: 3 camera trigger wires, once triggered, automatically switches to its corresponding camera
Frame ratio: 16: 9
Dot pitch: 0.045(W)× 0.135(H)
Resolution: 800(H)× 480(V)
Brightness: 400 cd/
Contrast: 500: 1
Viewing angle: U: 50° , D: 70° , L/R: 70°
Power consumption: 5W
Power supply: DC: 10-32V
Operating temperature: -20º C~+70º C
Storage temperature: -30º C~+80º C

Autoshutter camera features:

Extra smaller

Stainless-steel sun-shield and U-bracket

With auto shutter

Super wide angle (180° )

Automatic heating when the camera's running temperature is below 10º C(optional)

Performs in rugged conditions

Distance label selectable to be open or closed

Waterproof and weather resistant housing for outdoor use

Night vision available, day/ night sensor for automatic adjustment

IR distance: Approx. 10m

Infrared LED light: 6

Mirror/ Normal image switch (depending on the chips)

PC1089 Features:

Pixelplus 1/3", 500 TV lines, high definition CMOS sensor: PC1089K

Wide power supply input: 8V ~32V; Working temperature: -40° C~70° C.

With infrared lights; Night vision can auto switch to B/W mode. Good night vision performance, small noise

And no color aberration.

IR-CUT optional, effectively avoid color aberration in daylight. Eg. Shooting green plant in high fidelity in the daylight.
