Product Specifications
| Prod Model: |
ZL50GL |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Load: |
5000kgs or 11000lbs |
| Grade-Ability: |
30 |
| Engine Model: |
Sc11CB220g |
| Rated Power: |
162kw |
| Tires: |
23.5-25-16pr |
| Bucket Capacity (Standard): |
3.0 M3 or 3.9 Cubic Yards |
| Wheelbase: |
3300mm |
| Operating Weight: |
17.5tons |
| Overall Dimension (Lxwxh): |
8165*3016*3485mm |
| Rated Speed: |
2000r/Min |
| Walking Mode: |
Wheeled |
| Condition: |
New |
| Type: |
Medium-sized Loader |
| Certification: |
ISO9001: 2000 |
| Load And Unload Method: |
Front Discharge |
Product Description
Introduction
XCMG ZL50GL loaders using the third generation of Chinese most outstanding representatives ZL50G platform design and development, high starting point, high-tech, high-performance, high-quality, low energy consumption.
Low-speed engine, torque converter to accommodate large, super heavy, compared with ordinary type loaders energy ≥ 12%.
Cab, hood damper noise reduction, noise reduced by 6 decibels (dB) or more, greatly improving ride comfort.
Pilot control, automatic leveling, elegant luxury, ride comfort.
Pilot control
The proportion of single-lever hydraulic pilot control system, control precision, Easy operation, operating force of only ordinary products, 1/3.
Double pump confluence
The hydraulic system adopts double pump confluence of technology to reduce the loss of hydraulic power, reduce the load on the engine, hydraulic components to improve reliability, improve work efficiency of the system.
Flow amplification
Pilot steering system uses a low-pressure low flow pumping oil to promote the flow amplifying valve spool to control the movement of the steering cylinder leading to high pressure and large flow of oil, manipulation force is small, relaxed and comfortable.
Double limit
Hydraulic steering limit flexibility and mechanical rigidity double limit, hydraulic control limit precedence mechanical limit, no shock, no damage.
Two-way damping
Power system uses two-way damping technology, comprehensive elastic suspension, powertrain and chassis effectively overcome the resonance between reducing noise and power system fatigue damage.
Automatic leveling
Bucket angle inductance control can be achieved anywhere in the level automatically, without having to adjust again loading shovel bucket angle, simplifies driver operations, improve work efficiency.
Driving comfort
The new styling, automotive equivalent level of luxury air-conditioned cab, interior space, interior appearance, wide field of vision. Multi-dimensional air windows, both fast defrosting, but also to meet the operator of the heating and cooling needs.
Freely adjustable seat and direction control, XCMG slippery floors, non-slip stand, injection instrument panel and control box layout sciences, with front and rear wiper, all reflect the "people-oriented" design concept, giving the operator the most comfortable working environment.
Dust and noise
Cab noise reduction processing damping hood, the triple composite noise, noise reduced by 6 decibels (dB) or more.
Cab dust-proof design to ensure that the work environment free from outside interference.
Safe operation
Four gas cap oil brake caliper disc with power cut off selector switch, both start-up performance and ramps and other complex road safety of operations.
Parking brake and emergency brake "Combo", the role of low pressure and low pressure of start automatic protection function, traffic, parking safe and reliable. Brake pump with a dust respirator.
Operation countertop using punching skid measures; Ladder stairs layout, easy on and off, ladders wide, safe to use.
Easy maintenance
High reliability lifting mechanism on the engine cover, internal parts completely exposed, easy inspection and maintenance.
Rear fuel filler, fuel adding more convenient, improve machine stability.
Hydraulic tank using an independent oil return chamber structure, easy maintenance.
|
Description |
Specification |
unit |
|
Rated load |
5000kgs |
kg |
|
Tipping load |
123kgs |
|
|
Dump height |
3090 |
mm |
|
Unloading distance |
1130 |
mm |
|
Lifting height |
5262 |
mm |
|
Bucket width |
3000 |
mm |
|
Maximum breakout force |
170 |
KN |
|
Max. traction force |
160±5 |
KN |
|
Articulation angle |
±35 |
° |
|
Overall dimension (LxWxH) |
8165×3016×3485 |
mm |
|
Operating weight |
17.5 |
t |
|
Boom Time |
6 |
s |
|
Wheelbase |
3300 |
mm |
|
Track |
2250 |
mm |
|
Min. turning radius |
6400 |
mm |
|
Grade-ability |
30 |
° |
|
Engine model |
SC11CB220G |
|
|
Rated power/rated speed |
162/2000 |
kW/r/min |
|
Tires |
23.5-25-16PR |
|
