Product Specifications
Prod Model: |
1880mm |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
Various |
Operation: |
Automatic |
Quality: |
High |
Price: |
Competitive |
Process: |
Paper Machine |
Usage: |
Household Paper Machine |
Automatic Grade: |
Automatic |
Computerized: |
Yes |
Type: |
Toilet Paper Making Machine |
Certification: |
ISO |
Product Description
Technical parameters:
1, raw material: Waste paper and pure wood pulp;
2. Output paper: High and middle grade tissue paper
3. Output weight: 13-36G/M²
4. Net paper width: 1880mm
5. Wire width: 2150mm
6. Capacity: 5T/D
7. Working speed: 150m/min
8. Rail gauge: 2900mm
9. Drive: AC converter frequency conversion, adjustable speed, drive step by step
10. Standard of design: National standards for the export of equipment.
Main structure of equipment:
1. Cylinder part:
Cylinder section: Stainless steel cylinder 3 sets, couch roll 3sets, reverse roll 1set
2. Dryer part: Alloy dryer can (1PC); Coach roll (1 PC); Pneumatic pressure device. Equipped With duplex air bells cap.
3. Reeling part: One roll cylinder, reel paper on sweat cylinder
4. Rewinding and cutting:
Cooling cylinder (1PS), rubber rider rubber roll (1PC). Winding on the sweat cylinder.
5. Transmission & Control Division: AC frequency converter and adjustable speed, processing transmission
NO. |
Equipment |
Qty(set) |
1 |
1880mm single cylinder single wire &
single felt high speed tissue paper machine |
1 |
2 |
Double-dryer exhaust hood |
1 |
3 |
800axial-flow fan |
1 |
4 |
Mould former |
1 |
5 |
15 type roots pump |
1 |
6 |
Suction box |
2 |
7 |
5m3 High consistence hydrabrusher |
1 |
8 |
380 double disc refiner |
2 |
9 |
0.6pressure screen |
1 |
10 |
606 desander 12pcs |
4 group |
11 |
Φ700thruster |
4 |
12 |
8inch pulp pump |
2 |
13 |
6inch pulp pump |
6 |
14 |
6inch white water pump |
2 |
15 |
Two-phase flow pump-150 |
4 |
16 |
workbench |
1 |
17 |
Frequency control cabinet |
1 |
18 |
Air pump cabinet |
1 |
Our company has over 420 employees. There are five factories in China with the total area of 20, 000m2, it has passed the ISO14001 international authentication
Our products include paper making machines, parts and paper processing machines such as kraft paper machine, tissue paper machine, cultural paper machine, fiber separator, hydrapulper, rewinder, napkin folder, tisue slitter and ao on. They have been exported to more than 8countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying in perfect & advanced technology, sincere service and inexpensive products with high quality, we have won the recognition of international market and clients
Why choose us
Our company gathers a technique team of engineers and experts with over 30 years' experience which helps us be a professionall on all kinds of paper making machines and make us competitive on the market. We focus on quality and customers' need and improve our technology and service continually. We believe our devotion to work will help us to achieve global leadership in providing first-class products and superior quality services to customers around the world
Our advantages
Technical advantage
1. Experiences producing team
2. Advanced technological strength
Product advantage
1. Through the international authentication
2. Same material with most preferential price
3. A lot of varieties for the customer to choose
Service advantages
1. Technical consultation
2. Project evaluation
3. Detailed design of factory
4. Installation and test the whole production line
5. Training engineers and workers
6. Supplying spare parts for long time
