Rui'an Changhong Printing Machinery Co., Ltd. >> 6 Color Flexo Printing Machinery (CH886)

6 Color Flexo Printing Machinery (CH886)

Name: 6 Color Flexo Printing Machinery (CH886)
Brand: china-manufacturer-directory.com
SKU: 673168745
Availability: InStock
Rating: 4.5 (108 reviews)

Supplier:	Rui'an Changhong Printing Machinery Co., Ltd.
Price:	US $ 10000-60000/Set
Min Order:	1/Set
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	CH886
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Printing Material:	Tissue Paper, Serviette
Anilox Roller:	Ceramic Anilox Roller
Ink Supply Device:	Doctor Blade
Ink Cycle:	Ink Pump
Printing Roll Lift System:	Bu Hydrulic
Color & Page:	Multi-Colour Printing Press
Plate:	Relief Printing
Embossing Structure:	Rotary Letterpress
Type:	220V/380V,3p,50/60Hz
System Supported:	220V/380V,3p,50/60Hz
Printing Interface:	220V/380V,3p,50/60Hz
Printing Speed:	60m/Min

Product Description

The main features:
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7. Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8. With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Prrint produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll,

Model Item	CH884- 330MZ	CH884-500MZ	CH884-800MZ		CH806-330MZ	CH806-500MZ		CH806-800MZ
Material	17g-80g Tissue paper
Material width	400mm	600mm	900mm		400mm	600mm		900mm
Printing color	Four color	Four color	Four color		Six color	Six color		Six color
Material specifications	330 ×330	330 ×330 450 ×450 600 ×600	330 ×330 450 ×450 600 ×600 900 ×900		330 ×330	330 ×330 450 ×450 600 ×600		330 ×330 450 ×450 600 ×600 900 ×900
Register precision	Longitude ±0.20mm Transverse ±0.20mm
Printing length	200-330mm	200-600mm		200-900mm		200-330mm	200-600mm		200-900mm
Anilox cylinder	80-160DK German made Titanium roller
Printing plate lifting system	Pneumatic/Hydraulic press control
Mechanical speed	100m/min
Printing speed	80m/min
Output(sheet/hr)	14000	14000 10000 8000	14000 10000 8000 5100		14000	14000 10000 8000		14000 10000 8000 5100
Rewinder/Unwinder DIA	ø 600mm/ø800mm
Master electric machinery	2.2KW	3KW	3.7KW		3KW	3.7KW		4KW
Rewinder motor	1.1KW	1.1KW	1.5KW		1.1KW	1.1KW		1.5KW
Dryer	0.75KW	0.75KW	1.1KW		0.75KW	0.75KW		1.1KW
Powder brakes	2.5Kg	5Kg	5Kg		2.5Kg	5Kg		5Kg
Paper magnetic powder clutch	5Kg	5Kg	10Kg		5Kg	5Kg		10Kg
Tension sensor	2-10 Kg	2-15 Kg	2-20 Kg		2-10 Kg	2-15 Kg		2-20 Kg
Aridity Mode	6KW	8KW	11KW		8KW	10KW		14KW
Master power	10KW	12KW	15KW		12KW	15KW		20KW
Weight	5010Kg	5350 Kg	6150 Kg		5960 Kg	6350 Kg		7350 Kg
Dimension (L ×W ×H)	3.85m × 1.55m × 2.6m	3.85m × 1.7m × 2.65m	3.85m × 2.0m × 2.7m		4.0m × 1.6m × 3.1m	4.0m × 1.8m × 3.2m		4.0m × 2.2m × 3.3m

Located in Ruian, Zhejiang, Ruian Changhong Machinery Factory is a manufacturer of printing machinery which specializes in the production of flexographic printing machines.

Over the years, we have been sticking to the enterprise concept that the management of an enterprise is the management of talents. Every staff member takes "customer satisfaction as the supremacy. with our confidence and ceaseless efforts, we firmly believe that our enterprise will have a more splendid future!

Changhong Machinery Factory is mainly engaged in design and manufacturing of printing machines. At present, with the Project Department, the Technical Service Department and the New Product Research Center which all boast tremendous strength, it is capable of independently developing new flexographic printing machines. Machinery products developed in the recent years, such as high-speed computerized chromatic flexo printing machines, high-speed cascading flexo printing machines and in-line flexo printing machines, are exported to various regions and countries including Eastern Europe, North America, South America, Southeast Asia, Russia, Africa, Middle East, etc., which have received good market feedback and positive comments from customers.

The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
