Product Specifications
| Prod Model: |
CH886 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Printing Material: |
Plastic Film Material |
| Anilox Roller: |
Ceramic Anilox Roller |
| Ink Supply Sytem: |
Doctor Blade |
| Printing Roll Lift System: |
by Hydrulic |
| Tension For Unwind And Rewind: |
Automatic Tension Controller |
| EPC For Unwind: |
Edge Position Controller |
| Type: |
Ink Jet |
| Plate: |
Relief Printing |
| Embossing Structure: |
Rotary Letterpress |
| Color & Page: |
Multi-Colour Printing Press |
| Printing Speed: |
30-80m/Min |
Product Description
Changhong Machinery Company is mainly engaged in design and manufacturing of printing machines. It is capable of independently developing new flexographic printing machines.
Machinery products developed in the recent years, we have many kinds machine, such as normal-speed 10-60m/min, Middle-speed 10-100m/min, , high-speed over 120m/min standards.
The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.If need any video or data about our machine, pls contact Linda wu: 0086-18857728175!
1. The main features:
1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for group control.
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll
2. Machine process:
Unwinding unit-----auto tension controller for unwind ------EPC for correct position ---------Flexo printing -----------Heating and drying -------Rewinding Unit
3. Machine different requires:
1) machine width require:
Standard: 600, 800, 1000, 1200, 1400, 1600mm
Special: 1800, 2000, 2200, 2400m, 3200mm etc.
2) machine speed require:
Standard / normal speed: 10-60m/min
Middle speed: 10-90m/min
High speed: 10-130m/min
3) machine printing material require:
Standard 1: For plastic film, PE, PP, OPP, HDPE, LDPE, etc. And 30-150gsm paper
Standard 2: Only for paper, 50-350gsm
Standard 3: Only for non woven material
Special design: For alumnium foil, pp woven bag etc.
If you want to talk further about machine you require, pls contact Linda wu: 0086-18857728175!
Printing width
Item | 600mm | 800mm | 1000mm | 1200mm | 1400mm | 1600mm | 1800mm | 2000mm |
| Printing color | PC:6+0;5+1;4+2;3+3 |
| Printing length | 7.5 ″-40 ″/7.5 ″-50 ″/7.5 ″-60 ″/7.5 ″-70 ″/7.5 ″-80 ″ |
| Printing plate lifting system | Pneumatic/Hydraulic press control/Menu |
| Mechanical speed | 90m/min |
| Printing speed | 70m/min |
| Anilox cylinder | Metal: 10DK-120DK(Germany) |
| Register precision | Longitude ±0.25mm Transverse ±0.25mm |
| Rewinder/Unwinder DIA | ø 600mm |
| Master motor | 3.7KW | 3.7KW | 5.5KW | 5.5KW | 7.5KW | 7.5KW | 11KW | 11KW |
| Unwinder motor | 1.1 KW | 1.5 KW | 2.2 KW | 3.0 KW |
| Rewinder motor | 1.5 KW | 2.2 KW | 3.0 KW | 3.7KW |
| Electrical header | 14KW | 16KW | 20KW | 22KW | 24KW | 26KW | 28KW | 30KW |
| Blower of header | 1.5KW ×2 | 1.1KW ×3 | 1.1KW ×3 | 1.1KW ×3 | 1.5KW ×3 | 1.5Kw ×3 | 2.2KW ×3 | 2.2KW ×3 |
| Blower of nature wind | 0.75 KW | 0.75 KW | 1.1 KW | 1.1 KW | 1.1 KW | 1.5KW | 1.5KW | 1.5KW |
| Inking motor | 750W | 750W | 750W | 750W | 750W | 750W | 750W | 750W |
| Master frequency converter | Panasonic/ Toshi batransducer Japan |
| Bearing | Japan (NSK) |
| Unilateral bearing | ASNU (Germany) |
| Weight | 4500Kg | 4750Kg | 56000Kg | 5250 Kg | 5500Kg | 5750Kg | 6000Kg | 6300 Kg |
| Master power | 25KW | 27KW | 34KW | 37KW | 43KW | 47KW | 55KW | 58KW |
Dimension
(L ×W ×H) | 4.8m
×
1.8m
×
2.8m | 4.8m
×
2.0m
×
2.8m | 4.8m
×
2.2m
×
2.8m | 4.8m
×
2.4m
×
2.8m | 4.8m
×
2.6m
×
2.8m | 4.8m
×
2.8m
×
2.8m | 4.8m
×
3.0m
×
2.8m | 4.8m
×
3.2m
×
2.8m |
Located in Ruian, Zhejiang, Ruian Changhong Machinery Factory is a manufacturer of printing machinery which specializes in the production of flexographic printing machines.
Over the years, we have been sticking to the enterprise concept that the management of an enterprise is the management of talents. Every staff member takes "customer satisfaction as the supremacy. with our confidence and ceaseless efforts, we firmly believe that our enterprise will have a more splendid future!
Changhong Machinery Factory is mainly engaged in design and manufacturing of printing machines. At present, with the Project Department, the Technical Service Department and the New Product Research Center which all boast tremendous strength, it is capable of independently developing new flexographic printing machines. Machinery products developed in the recent years, such as high-speed computerized chromatic flexo printing machines, high-speed cascading flexo printing machines and in-line flexo printing machines, are exported to various regions and countries including Eastern Europe, North America, South America, Southeast Asia, Russia, Africa, Middle East, etc., which have received good market feedback and positive comments from customers.
The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
