Product Specifications
Prod Model: |
CH886 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Printing Material: |
PE, PP, OPP, HDPE Film |
Anilox Roller: |
Ceramic Anilox Roller |
Inksupply Device: |
Doctor Blade |
Printing Roller Lift System: |
by Hydrulic |
Tension For Unwind And Rewind: |
Auto Tension Controller |
EPC For Unwind: |
Edge Position Controller |
Color & Page: |
Multi-Colour Printing Press |
Plate: |
Relief Printing |
Embossing Structure: |
Rotary Letterpress |
Printing Speed: |
30-80m/Min |
Product Description
6 Colour Film Flexo Printing Machine
The main features:
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7. Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8. With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Prrint produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
Printing width Item |
600mm |
800mm |
1000mm |
1200mm |
1400mm |
1600mm |
1800mm |
2000mm |
Printing color |
PC: 6+0; 5+1; 4+2; 3+3 |
Printing length |
7.5 ″ -40 ″ /7.5 ″ -50 ″ /7.5 ″ -60 ″ /7.5 ″ -70 ″ /7.5 ″ -80 ″ |
Printing plate lifting system |
Pneumatic/Hydraulic press control/Menu |
Mechanical speed |
90m/min |
Printing speed |
70m/min |
Anilox cylinder |
Metal: 10DK-120DK(Germany) |
Register precision |
Longitude ± 0.25mm Transverse ± 0.25mm |
Rewinder/Unwinder DIA |
ø 600mm |
Master motor |
3.7KW |
3.7KW |
5.5KW |
5.5KW |
7.5KW |
7.5KW |
11KW |
11KW |
Unwinder motor |
1.1 KW |
1.5 KW |
2.2 KW |
3.0 KW |
Rewinder motor |
1.5 KW |
2.2 KW |
3.0 KW |
3.7KW |
Electrical header |
14KW |
16KW |
20KW |
22KW |
24KW |
26KW |
28KW |
30KW |
Blower of header |
1.5KW × 2 |
1.1KW × 3 |
1.1KW × 3 |
1.1KW × 3 |
1.5KW × 3 |
1.5Kw × 3 |
2.2KW × 3 |
2.2KW × 3 |
Blower of nature wind |
0.75 KW |
0.75 KW |
1.1 KW |
1.1 KW |
1.1 KW |
1.5KW |
1.5KW |
1.5KW |
Inking motor |
750W |
750W |
750W |
750W |
750W |
750W |
750W |
750W |
Master frequency converter |
Toshi batransducer Japan |
Bearing |
Japan(NSK) |
Unilateral bearing |
ASNU (Germany) |
Weight |
4500Kg |
4750Kg |
56000Kg |
5250 Kg |
5500Kg |
5750Kg |
6000Kg |
6300 Kg |
Master power |
25KW |
27KW |
34KW |
37KW |
43KW |
47KW |
55KW |
58KW |
Dimension
(L × W × H) |
4.8m
×
1.8m
×
2.8m |
4.8m
×
2.0m
×
2.8m |
4.8m
×
2.2m
×
2.8m |
4.8m
×
2.4m
×
2.8m |
4.8m
×
2.6m
×
2.8m |
4.8m
×
2.8m
×
2.8m |
4.8m
×
3.0m
×
2.8m |
4.8m
×
3.2m
×
2.8m |
Located in Ruian, Zhejiang, Ruian Changhong Machinery Factory is a manufacturer of printing machinery which specializes in the production of flexographic printing machines.
Over the years, we have been sticking to the enterprise concept that the management of an enterprise is the management of talents. Every staff member takes "customer satisfaction as the supremacy. with our confidence and ceaseless efforts, we firmly believe that our enterprise will have a more splendid future!
Changhong Machinery Factory is mainly engaged in design and manufacturing of printing machines. At present, with the Project Department, the Technical Service Department and the New Product Research Center which all boast tremendous strength, it is capable of independently developing new flexographic printing machines. Machinery products developed in the recent years, such as high-speed computerized chromatic flexo printing machines, high-speed cascading flexo printing machines and in-line flexo printing machines, are exported to various regions and countries including Eastern Europe, North America, South America, Southeast Asia, Russia, Africa, Middle East, etc., which have received good market feedback and positive comments from customers.
The products of Changhong mainly feature stable and simple operation, good durability, simple maintenance, even inking, strong stability and long service life.
