Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,CIF,EXW |
Min Order: | 1/Piece |
Pay Type: | T/T,Paypal,Money Gram,Western Union |
Prod Model: | FNS-D256L-L |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Option: | Bypass |
Type: | Wired |
Application: | SOHO |
Transfer Rate: | 10/100/1000Mbps |
Ports: | 6 |
Model NO. |
FNS-D256L-L |
CPU |
Intel® Atom D2550 dual-core processor (1.86GHz) |
Chipset |
Intel® ICH10R Express Chipset |
Memory |
1* SO DDR3 Solt Support 800/1066MHz,Max.4GB |
Display |
1* DB15 VGA port |
Expansion |
1* MSATA, Support SSD/USB/WIFI |
1* PCI |
|
Ethernet |
Integrated 6* Intel 82583V 10/100/1000Mbps Ethernet ,Support Wake-on-LAN,PXE LAN1-4 Support 2 groups of Bypass (Option,require custom) |
Storage |
Providing a 3.5/2.5inch SATA disk location ,1* CF card slot |
Panel Port |
1* COM(compatible with CISCO Standard) |
2* USB 2.0 (Re-install system ,No need disassemble the chassis) |
|
6* LAN |
|
1* POWER |
|
1* LED (POWER LED / HDD LED) Indicator |
|
1* VGA port (Rear panel) Easy debugging |
|
FAN |
1* CPUFAN & 2* SYSFAN(3pin) |
WatchDog |
Integrated:256 level,0~255min |
Anti-vibration |
5~300Hz/random operating |
Power |
ATX Power supply |
Operate.Tem |
0°C~50°C |
Storage.Tem |
-20°C~70°C |
Operate.Hum |
5%-95% |
Humidity |
5%-95% (relative humidity; non-condensing) |
Installation |
1U Rack-mount |
Material and Process |
Surface sandblasting oxidation process (Silver gray) |
Size |
430mm(L)* 280mm(W)* 462mm(H) |
