6630 DMD Class-B Electrical Insulation Material Flexible Laminates

6630 DMD Class-B Electrical Insulation Material Flexible Laminates
Supplier: Henan Yaan Electrical Insulation Material Plant Co., Ltd.
Price: US $ 3.5kg
Min Order: 1 /Piece
Quantity::
Trade Terms: CIF
contact supplier

Product Specifications

Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Maximum Voltage: 20KV~100KV
Application: Motor
Chemistry: Inorganic Insulation
Type: Insulation Film
Thermal Rating: B 130
Material: Dacron, Polyester Non-Woven Fabric

Product Description

1. Production:
DMD-6630 is a three-layer combined electrical insulation flexible material produced by adhering the two faces of polyester film with Non-woven polyester fabric
2. Features and Aplication:
Excellent dielectric and mechanica property, high tensile strength and heat-resistance.
As slot, interturn, liner electrical insulation for B-grade motors and electrial appliances.
3. Availability:
Form: Roll, sheet, strip
Colur: White, pink, blue. Special colours can be provided on request.
DM or DMDM electrical insulation paper can be produced on request.
Properties Units Values
Nominal thickness mm 0.15 0.18 0.20 0.23 0.25 0.30 0.35
Thickness tolerance mm ± 0.02 ± 0.03 ± 0.03 ± 0.03 ± 0.03 ± 0.03 ± 0.04
Grammage and tolerance g/m 2 140± 20 190± 28 220± 33 260± 39 300± 45 350± 52 425± 63
Film Nominal Thickness mm 0.050 0.075 0.10 0.125 0.15 0.19 0.25
Tensile
Strength

MD No bending N/10mm ≥ 80 ≥ 120 ≥ 140 ≥ 180 ≥ 190 ≥ 270 ≥ 320
After bending ≥ 80 ≥ 105 ≥ 120 ≥ 150 ≥ 170 ≥ 200 ≥ 300
TD No bending ≥ 80 ≥ 105 ≥ 120 ≥ 150 ≥ 170 ≥ 200 ≥ 200
After bending ≥ 70 ≥ 90 ≥ 100 ≥ 120 ≥ 130 ≥ 150 ≥ 200
Elongation


MD
No bending
%
≥ 15 /
After bending ≥ 10 ≥ 5
TD No bending ≥ 20 /
After bending ≥ 10 ≥ 5
Breakdown Voltage
kV
≥ 6 ≥ 7 ≥ 9 ≥ 10 ≥ 12 ≥ 15 ≥ 18
Bonding property at room temp. / No delamination
Bonding property    at 155 + 2° C, 10 min / No delamination, no blister, no adhesive flow
The quality warranty period Twelve months(under 40 ° C )
YAAN Electrical Insulation Material Plant Co., Ltd. is a professional enterprise for producing electrical insulation materials. Since the plant was established in 1986, YAAN has maintained the core discipline: The high quality today is the market tomorrow; The satisfaction of the customers is the life of our enterprise" . YAAN has pursued the spirit of " Working hard and making a rapid progress" Over the past 20 years. It also has strict requirements for the quality, trying to return every customer with high quality product and good service. In the tide of the integration with global economy, YAAN has paid attention to the international market as well as keeping steady domestic market.

The Foreign trade department has established since 2003, now the products have exported to the market of South and North America, South Asia, South-East Asia, West-Asia as well as East-Europe, and won a high reputation in its quality and service for the foreign customers. YAAN has gradually developed into specialized enterprises which produce Class B, Class F and Class H insulation material. The main products lies in insulating varnish and resin, flexible laminates, woven tape, impregnated fiberglass binding tape, varnished fabric, insulation paper. The insulation system has been approved by UL (NO.: E310670) and the products have passed RoHS test.
