Product Specifications
| Prod Model: |
BL8P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module: |
Wavecom Q2406, Q2403, Q24plus, Q2426 |
| GSM Frequency: |
900/1800MHz, 850/1900MHz, 850/900/1800/1900MHz |
| Interface: |
USB |
| SMS Sending: |
4800-6400SMS Per Hous |
| Gross Weight: |
2.5kg |
| Open At Command: |
Support |
| IMEI Change: |
Support |
| Package Size: |
19.5*11.5*13cm |
| Shipment: |
DHL, FedEx, UPS, TNT, EMS, HK Post etc |
| Type: |
External |
| Interface Type: |
USB |
| Transmission Rate: |
14.4Kbps |
| Application: |
Industrial |
Product Description
Wavecom q24plus 8 port GSM modem IMEI changeable HK bailing
SPECIFICATION
PRODUCT FEATURESDual Band EGSM/GPRS module (EGSM 900/1800 MHz, EGSM850/1900MHz) designed
Compliant with ETSI GSM Phase 2+standard
Class 4 (2W @ 900 MHz)
Class 1 (1W @ 1800 MHz)
ENVIRONMENT AND
MECHANICSOperating temperature range: -20° C to +55° C
Storage temperature range: -30° C to +85° C
INTERFACESAntenna: RF Pad supporting coaxial cable
60 pins board to board connector
Including:
1.3V SIM interface with SIM detection
2.2 microphone inputs and 2 speaker
3. Outputs
4.1 SPI/I2C
5.10 input lines for 5X5 keypad
6.1 buzzer output
7.1 vibrator output
8.2 Analog to Digital Converters
9.2 RS-232 serial links
10. IrDA interface
11. Battery charging interface
AT commands interface:
GSM 07.05 and 07.07 AT commands
Comprehensive set of enhanced AT commands
Open AT APIs: Numerous interfaces for embedded applications
SIM Toolkit release 99
APPROVALS
The modules are approved worldwide
Under test standards including:
Radio and Telecommunication Terminal
Equipment (R&TTE), Global Certification
Forum Certification Criteria (GCF-CC),
EMC, Safety and Chinese approvals
VOICE FEATURES
Voice features (GSM mode):
1. Telephony, Emergency calls
2. FR, EFR, HR, AMR*
3. Echo Cancellation and Noise Reduction
DATA FEATURES
1. Data circuit asynchronous, transparent and non transparent up to 14400 bits/s
2. Fax group 3 (Class 1 and 2) GPRS packet Data features
3. Class 10
4. Coding Schemes: CS1 to CS4
5. PBCCH support
MESSAGE SERVICESPoint to point (MT/MO) and Cell Broadcast
GSM SUPPLEMENTARY
SERVICES
1. Call Forwarding, Call Barring
2. Multiparty
3. Call Waiting, Call Hold
4. USSD
ADDITIONAL PROTOCOLS
1. IP connectivity (TCP/IP with TCP/UDP sockets, POP3, SMTP, FTP)
2. IBM WMQT (Websphere)
3. Orange M2M Connect
Standard configuration
Main unit1PC
Power adaptor1PC
RS232 cable1PC
SMA Antenna1PC
Package size: 17*21*7cm
Gross weight: 0.5kg/box
Established in the year of 2006, Shenzhen Bailing Technology Co., Ltd is one of the leading manufacturers dedicated in telecommunication and security industry. We are specialized in manufacturing GSM wireless products like modem, modem pool, alarm system data monitors and long-range supervision systems for families, electric power, mobile base stations, transportation, petrolum finances, civil and police stations etc. What's more, we highly appreciate OEM /ODM business. We have a professional R&D team to help you with your multiple products requirement. Can according to your specific needs to design the best solution project for your market expansion Bailing adheres to the principle of Good quality, best service, customer satisfaction as our persuit.
Bailing's strict QC Management is adopted in every process of production. We gained ISO 9001 and ISO 14001 certificate. Bailing can provide products compliant with RoHS standard
Bailing People are trying best to be known in telecomunication and alarm industry, with worldwide customer's support and most advanced technical team, Bailing is on the move^ welcome to Bailing.
.
