Product Specifications
| Prod Model: |
PTP-III |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Products Status: |
Stock |
| Black Print Speed: |
50~80mm/S |
| Printing Life: |
15 Million Lines |
| Paper Type: |
Thermal Paper |
| Resolution: |
576 Dots/Line, 8 Dots/Mm |
| Paper Roll Diameter: |
Max:40mm |
| Weight: |
340g |
| Dimension: |
112W X 124D X 48h Mm |
| Effective Printing Width: |
72mm |
| Color: |
Black |
| Usage: |
Barcode Printer |
| Style: |
Black and White |
| Interface Type: |
Bluetooth, USB/IrDA/Wireless |
| Type: |
Thermal Line Printing |
| Max. Paper Size: |
58mm |
| Character Structure: |
Ascii, GB2312 |
Product Description
1. Product information:
Feature:
3 inch android driver receipt printer
Portable device suited for outdoor usage
Waterproof design
Black mark paper location sensor
Status supervision any time by an OLED display
Low battery indicator(7.4V,2000mAh)
Equipped with lithium battery for 8 hours continuous work
Vairous interface communication and interface capabilites
Bluetooth/Wifi with high communication speed
Easy paper loading
High printing speed , up to 80mm/s.
Application :
Mobile POS/Retail
Hospitality
Packing citation
Deliveries
Onboard Transportation
Field reparts/Installation
Warehouse/ logistics
Utility billing/meter reading
Specification:
Print | Printing Method | Thermal Line |
| Printing Speed | 50mm-80mm/s |
| Resolution | 576 dots/line |
| Effective Printing Width | 72mm |
| Character | Character Set | ASCII,GB2312-80(Chinese) |
| Print Font | ANK: 8x16,9x17,9x24,12 x24 Chinese: 24 x 24 |
| Paper Spec. | Paper Type | Thermal paper |
| Paper Width | 80±0.5mm |
| Paper Roll Diameter | Max: 40mm |
| Paper Thickness | 60 to 100um |
| Paper Supply Method |
| Drop-in Easy loading |
| Reliability | MCBF | 15 million lines |
| TPH | 50km |
| Barcodes | 1D | EAN-18, EAN-13, EAN-8, CODE39, CODE93, CODE128, CODABAR, ITF, UPC A, UPC B, Graphic |
| 2D | QR Code/PDF 417 |
| Emulation |
| ESC/POS compatible with commands set |
| Sensor |
| Paper End Sensor |
| Interface |
| PTP-III:RS232/USB; PTP-III/BT:RS-232/USB,Bluetooth; PTP-III/Ir:RS-232/USB, IrDA/Raw IR; |
| Mark position |
| Detecting mark position |
| Battery Power |
| 2000 mAh rechargeable Li-ion battery |
| Physical | Weight | 350g(Including battery & roll paper) |
| Dimension (WxLxH) | 110 x 124 x 48mm |
| Color | Black/Dark Gray
|
