The davit conforms to the relative requirements of MSC. 47(66) 1974 SOLAS Amendments, MSC. 48(66) LSA Code, IMO Resolution A689(17).
Technical data
Max. Working load: 30 KN
Hoisting load: 30KN
Lowering load: 30KN
Max. Hoisting height: 25 m
Hoisting Speed: ≥ 18 m/min
Lowering Speed: 40~60 m/min
Max List/Trim: List 20º / trim 10º
Operation Temperature Range: -10º C - + 45º C
Relative humidity: Above 85%
Winch data:
Wire diameter: Ø 18 mm
Wire length included: 40meters
Corrosion protection wire: Galvanized and anti-rotating
Inner wire end: Secured to drum
Outer wire end: Shackle and safety wire clamp
Winch motor:
Type: YZ160L-6-H
Power supply: 440V/60Hz/18.5kw
Protection grade: IP56
Insulation grade: F
Space heater to be provided with transformer
Pump motor:
Type: Y132M-4-H
Power supply: 440V/60Hz/5.5kw
Protection grade: IP56
Insulation grade: F
Space heater to be provided
Safety System:
The davit is fitted with the following safety systems:
The control levers are spring-centred. In order to operate the davit
Relevant control, Lever has to be pushed in the required direction to
Cause the desired motion. Once the lever is released it will return
Back to centre position, and the activated motion will cease immediately
Hook Safety: Set Limit Switch under 400mm to the head of jib to
Prevent from damage the head block;
Protection Grade of limit switch is IP56;
|
LIST OF DELIVERY |
PROD NAME |
PR30 RESCUE BOAT DAVIT |
|
CODE |
PR30-00GMX |
|
NO. |
NAME |
DWG. No. |
SKETCH |
QTY. |
NOTE |
\BARE PART |
|
1 |
PR30 RESCUE BOAT DAVIT |
PR30-00 |
|
1 |
|
|
2 |
LADDER |
PR30-08 |
|
1 |
|
|
\PACKING PARTS |
|
1 |
FASTENING UNIT |
BXL 50X10000 |
|
2 |
|
|
2 |
BOLT
NUT
WASHER |
M24X90
M24
24 |
|
20
20
20 |
10.9
8
65Mn |
|
3 |
SPARE PARTS |
|
SEE NEXT PAGE |
1 |
|
NOTE: QTY. IN TABLE IS FOR 1 SET DAVIT
|
