Product Specifications
| Prod Model: |
LH-AV 81 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Type: |
Analog and Digital |
| Measuring Range: |
0-9999 |
| Accuracy Class: |
0.5 |
| Operating Temperature: |
-10c ~+55c |
| Dimensions: |
48*48 |
| Name: |
Voltage Meter |
| Color: |
White and Black |
| Type: |
Energy Meter |
| Electric Equipment: |
Single-phase |
| Theory: |
Electronic Meter |
| Installation: |
Direct Connected |
| Usage: |
Maximum Demand Meter |
| Measured Signal: |
Continuous Wave |
| Power Meter Connection: |
Terminal |
| Display: |
LED Display Digital Meter |
Product Description
Packaging & Delivery
Packaging Details: Polybag+paperbox+export carton
Delivery Detail: Within 45 days after receipt of 30% payment by T/T
Specifications
1. Certificate: ISO, CE
2. Material: ABS
3. OEM available
4. Display: LED
5. Name: Voltage meter
|
Dimension: customized |
custom processing: Yes |
Measuring range: 0-9999 |
|
Model NO.: Lh-AV |
accuracy class: 0.5 |
Installation: embedded |
|
|
Usage: high precision measurement of single phase AC voltage |
Auxiliary power supply: DC 80V-270V, DC48V, DC24V, AC220V, AC380V, AC100V(V) |
|
Performance Characteristics |
|
High precision measurement measurement of single phase AC voltage |
|
Provide the digital tube display, local data query |
|
Programmable voltage ratio |
|
Support for RS-485 communication, Modubus-RTU protocol |
|
Support for switching input, output, analog quantity transmitting output |
|
Auxiliary power supply: AC/DC 80V~270V, AC220V, AC380V, AC100V, DC48V, DC 24V |
|
A variety of shapes, to meet the different requirements of the cabinet body electric circuit |
|
Technical Index |
|
Accuracy of measurement |
Electric current 0.5 |
|
Singal input |
Connection mode of single phase |
|
|
Rated voltage of AC 57.7V, AC 100V, AC 220V, AC 380V, DC 2V, DC 20V, DC 200V, DC 600V, DC600V |
|
|
Over load 1.2 times ( Continued ), 2 times / second ( instantaneous ) |
|
|
Power < 1VA/ phase |
|
|
Impedance > 300KΩ |
|
|
The frequency of 45~65Hz or DC |
|
Auxiliary power supply |
AC/DC 80V~270V, AC220V, AC380V, AC100V, DC48V, DC 24V |
|
|
Power consumption < 4VA |
|
Function module |
Communication interface 1 way RS-485 communication, Modbus-RTU protocol |
|
|
Baud rate: 1200~9600bps, the default 2400bps |
|
|
Switch input support 2 stem node input |
|
|
The switch output support 2 relay output, capacity: AC 250V/5A, DC 30V/5A |
|
|
Transmission output support 1 analog output: 0/4~20mA or 0~5/10V |
|
Environment |
Working temperature: -10° C ~+55° C |
|
|
Storage temperature: -25° C ~+70° C |
|
|
Relative humidity is less than 93%, no corrosive gas |
|
|
Elevation≤ 2500m |
|
Safety |
Insulation resistance > 100MΩ |
|
|
AC withstand voltage AC 2KV |
|
Electromagnetic compatibility |
ESD level 4 |
|
|
Electrical fast transient burst level 4 |
|
Selcction ofSpecification |
|
Digital Single phase AC Voltage Meter(9999 display) |
|
Model NO. |
Display |
Frame size(mm) |
Hole size(mm) |
Remark |
|
Lh-AV11 |
Digital Single-row LED |
160*80 |
152*76 |
|
|
Lh-AV21 |
Digital Single-row LED |
120*120 |
111*111 |
|
|
Lh-AV31 |
Digital Single-row LED |
96*96 |
92*92 |
|
|
Lh-AV41 |
Digital Single-row LED |
120*60 |
114*56 |
|
|
Lh-AV51 |
Digital Single-row LED |
96*48 |
92*45 |
|
|
Lh-AV61 |
Digital Single-row LED |
72*72 |
68*68 |
|
|
Lh-AV71 |
Digital Single-row LED |
80*80 |
76*76 |
|
|
Lh-AV81 |
Digital Single-row LED |
48*48 |
45*45 |
|
|
Extended Modules: |
|
AC/DC power supply(switching power supply)$4 |
|
Order notes: Please write clearly the requested types, input signal and the functional modules, etc when purchasing. |
|
Others: Factory default settings (Use default setting if no instruction). |
