Aet62 NFC Reader with Fingerprint Sensor
Product Specifications
| Prod Model: |
AET62 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimensions: |
121.5 Mm (L) X 53.9 Mm (W) X 28.4 Mm (H) |
| Weight: |
170 G |
| Interface: |
USB Full Speed |
| Supply Current: |
Max. 300 Ma |
Product Description
Aet62 NFC Reader with Fingerprint Sensor
Feature
*Integrated fingerprint scanner and 13.56 MHz contactless (RFID/NFC) smart card reader
*Full-speed USB interface
*Encrypted fingerprint template stored inside smart card
*ACR122U NFC Contactless smart card reader:
Compliant with PC/SC and CCID specifications
Read/write speed up to 424 kbps
Built-in antenna for contactless tag access, with reading distance of up to 30 mm (depending on tag type)
Supports ISO 14443 Type A and B, Mifare, FeliCa, and all 4 types of NFC (ISO/IEC 18092) tags
Supports new MiFare Ultralight C, Plus SL1 (4 Byte UID), Plus SL3, and DESFire EV1
Supports all 3 modes of NFC: Reader, card emulation and peer-to-peer Built-in anti-collision feature (only one tag can be accessed at any time)
ISO 7816 Compliant SAM Slot (Upon request)
*Fingerprint scanner:
*Match-on reader: Template extraction and matching algorithms run within the device itself, not in the PC (Using default fingerprint algorithm)
*UPEK TCS4-TCD50 swipe fingerprint sensor
*Swipe speed of up to 40 cm/sec (15 in/sec)
*Active sensor size - 9.6 mm x 0.2 mm
*High-resolution 508 DPI imaging, array size 192 x 4 pixels
*Supports image optimization and filtering
*Utilizes CMOS active capacitive pixel-sensing technology, resulting to high-quality fingerprint images in any environment
*Compliant with BioAPI 1.1 specification and Windows Biometric Framewor
*Supports 3rd-party fingerprint algorithms
| Dimensions | 121.5 mm (L) x 53.9 mm (W) x 28.4 mm (H) |
| Weight | 170 g |
| Interface | USB Full Speed |
| Operating Distance | Up to 30 mm (depends on the tag type) |
| Supply Voltage | Regulated 5V DC |
| Supply Current | max. 300 mA |
| Operating Temperature | 0 - 50 °C |
| Smart Card Interface Support | ISO 14443 Type A and B
MiFare
FeliCa
4 types of NFC (ISO/IEC 18092) tags |
| Compliance/Certifications | PC/SC, CCID, BioAPI 1.1, Windows Biometric Framework, CE, FCC, RoHS, USB Full Speed
Microsoft WHQL XP, Vista, 7 |
| Operating System Support | Win 2000, Win XP, Win Vista, Win 7, Win Server 2003, Win Server 2008,Win Server 2008 R2
Linux |
