Anchor Pull Gauge

Name: Anchor Pull Gauge
Brand: China-Manufacturer-Directory.com
SKU: 700166182
Availability: InStock
Rating: 4.8 (63 reviews)

Supplier:	Beijing Samyon Instruments Co., Ltd.
Price:	US $ 1000-5000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	30T
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Capability:	0-300kn/0-63kpa
Resulution:	0.01kn
Tension Stroke:	60mm
Center Hole:	27mm
Error:	=<+/-2%F.S

Product Description

Executive Standard
GB50367-2006 Design code for strengthening concrete structure

Product introduction:
The instrument is suitable for testing the anchorage force of various of anchor shank, rebar and expansion bolts, also for testing the pull force of glass block screen wall.

Features:
Capability: 100kN /200kN /300kN
Digital pressure meter feature is liquid crystal display, direct force reading, peak holding, data storage, curvature correction, automatic shutdown
Hydraulic cylinder hollow reset
Special type in coal mine: LDS-100/200/300
Can change with handheld meter, high precision

Configuration:
1. Manual hydraulic oil pump
2. Hydraulic oil cylinder
3. Digital pressure gauge
4. High-pressure hose
5. Anchorage, connector(optional)

Model		SKZY-10	SKZY-20		SKZY-30
Manual pump	Pressure	63MPa	63MPa		63MPa
	Weight	8kg	10kg		10kg
	Packing case weight	5.5 kg	6kg		6kg
Oil cylinder	Capability:	100KN	200KN		300KN
	Tension stroke:	60mm	80mm		70mm
	Weight:	7kg	13kg		15kg
	Central hole:	27mm	34mm		45mm
Digital pressure gauge	Measurement range	0-100KN	0-200KN		0-300KN
	Power supply	2pcs No.5 battery	2pcs No.5 battery		2pcs No.5 battery
	Weight	0.34kg	0.34kg		0.34kg
Anchorage specifications (Optional)	φ6, φ8, φ10, φ12, φ14, φ16, φ18, φ20, φ22, φ25, φ28, φ32, φ36, φ38, φ40
Connector specifications (Optional)		M6, M8, M10, M12, M14, M16, M18	M6, M8, M10, M12, M14, M16, M18, M20	M6, M8, M10, M12, M14, M16, M18, M20, M22, M24

SAMYON commit us supply professional line instruments and service to our clients refers to Building, Bridge, Highway, Channel, Airport and so on.

Our service and equipment include:

1. Geophysical exploration Consultation and relative instruments such as: IP& Resistivity systems, Fluxgate Magnetometer, Optical pump Magnetometer, Proton Magnetometer, TEM, EM system, Seismograph, Logging system, etc.

2. Construction lab and NDT instruments: Ultrasonic Cross-Hole Pile Tester, Integrity Pile tester, Rebar Locator, Concrete Chloride Migration Tester( RCM), ect.

3. We are also distributor of Petroleum equipment and accessories, to supply our clients inquiry.

With our engineer and professional technology team, we hope we can cooperate with you in future. Relative consultation service, mainly refers to Building, Bridge, Highway and lab. Relative consultation service, mainly refers to Building, Bridge, Highway and lab.
