Qingdao Sanchuan Electric Power Equipment Co., Ltd. >> Angular Power Transmission Tower

Angular Power Transmission Tower

Name: Angular Power Transmission Tower
Brand: China-Manufacturer-Directory.com
SKU: 698661782
Availability: InStock
Rating: 4.6 (23 reviews)

Supplier:	Qingdao Sanchuan Electric Power Equipment Co., Ltd.
Price:	US $ 1100-1300/Ton
Min Order:	10/Ton
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	10kv-500kv
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Surface Treatment:	Hot-DIP Galvanized
Welding:	CO2 Welding or Submerged Arc Auto Methods
Height:	9-100m, According to Your Parameters
Material:	Q235, Q345, Q420 and Your Requests
Voltage:	10-500kv
Life Span:	50years
Bolts And Nuts:	Grade 4.8, 6.8, 8.8 and According to Your Standard
Export Markets:	Global
Style:	Independence Tower
Certification:	ISO
Structure:	Y Type
Usage:	Branching Tower
Materials:	Steel
Conductor Circuit:	Double Circuit
Standard:	Standard

Product Description

We are a professional manufacturer in steel structure, telecom tower, electric transmission line steel tower(angle steel tower and pipe steel tower 10KV-500KV), polygonal steel pipe/tube, street light pole and other welded steel products. We have mechanical physical laboratory, chemical laboratory, welding quality test laboratory to test our products' quality, meanwhile we strictly control every part's quality of the entire manufacturing process. Warmly welcome the friends from all over the world to cooperate with us.

Description:

Shape	Angle or pipe
Material:	Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm² As well as Hot rolled coil from ASTM A572 GR65, GR50, SS400
Height:	9-100m
Voltage	10KV-500KV
Welding Standard	AWS (American Welding Society ) D 1.1 CO2 welding or Submerged arc auto methods
Appearance	Hot DIP Galvanized
Certificate	ISO 9001: 2008, etc
Welding method	CO2 welding or submerged arc welding
Strength	Against earthquake of 8 grade
Wind Speed	Against 160 Km/Hour. 30 m /s
Surface treatment	Hot DIP galvanized Following ASTM A 123, or any other standard by client required. Thickness< 5mm, galvanization thickness≥ 460G/M² (65um) Thickness> 5mm, galvanization thickness≥ 610G/M² (86um)
Packages	Packing with plastic paper or according to client's request.

1. Our products have high resistance ability against heat, humidity, wind, snow etc.
2. Advanced wormanship is used to ensure its high precision, good quality during production and installation.

FAQ:
1. Port of Loading: Qingdao, China
2. Price term: FOB, CIF. The price 950~1200USD/Ton(based on different material and production procedure)
3. Payment Term: 30%TT deposit in advance, 70%TT balance against B/L.
4. Time of delivery:as clients' request or contract
5. Manufacture products as clients' drawing

Established in 2006, Qingdao Sanchuan Power Equipment Co., Ltd. is a manufacturer which specializes in the research, development and production of steel towers(power transmission tower and telecom tower), steel structure and other welded steel products. We are located in Qingdao, with convenient transportation access, 50KM from the Qingdao Port (the third big port of China). We have 103 staff and the factory covers an area of 14000 square meters, building area of 7000 square meters. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. We could design and manufacture products as clients order. We have mechanical physical laboratory, chemical laboratory, welding quality test laboratory to test our products' quality, meanwhile we strictly control every part's quality of the entire manufacturing process. Warmly welcome the friends from all over the world to cooperate with us.
