Animal Feed Machine

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Processing Technice:	Pellet Making Process
Types:	Pellet Mill
Capacity:	0.5-20t/H
Color:	Can Be Customed
Material:	Carbon Steel
Processing Technics:	Crushing-before-Mixing
Processing Object:	Animal-Derived Feed
Type:	Pellet Mill

Product Description

Pelletizing is the process of making waste materials into solid fuel. The pellets are then used for thermal combustion. Feed pellets are one of the most common products of pelletization. Feed pellets can be made from any type of corn, sorghum, bran, soy, wheat, born flour, rice flour or rice hulls, coffee husks, paddy straw, sunflower stalks, mustard, soybean, coconut and others. The moisture content should be less than 15%.

(1). Crushing Process---feed pellet machine

When the thickness of the raw material is >10 mm, and >50 * 50 mm (L * W), the raw materials must first be used for size reduction before the feedstock is sent to the hammer mill (crusher) to reach a diameter of less than 3 mm.

(2). Mixing Process---feed pellet machine

A. The feed mixer equality of mixing is below 7 percent.

B. The rim for sending materials is quite big. There is quite few material left in the machine.

C. This feed mixercomprehensively applies in matching feed factory, chemical industry, food, flour and other sectors Mixed in gravity-free state, no segregation, variety of liquids can be added. Conveyed by three chains, run in low speed, stable operation movement. Short mixing period(40-120 sec/batch), high evenness degree (CV5%) may be up to 2%

D. Two open doors structure, discharge rapidly, no leakage, no residue. Multiform liquid adding system and can be matched with compressed air jetting system Suitable for mixing premix, poultry feed, aquatic feed, additives and chemical and medicine industries, etc

(3). Pelletizing Process---feed pellet machine
