Anping Stainless Steel Crimped Wire Mesh/Crimped Mesh
Product Specifications
| Prod Model: |
XL-FY858 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wire Diameter: |
6.0mm |
| Mesh Size: |
0.58-20 Mesh |
| Material: |
Stainless Steel Wire |
| Application: |
Cages |
| Hole Shape: |
Square |
| Weave Technique: |
Twill Weave |
| Weave Method: |
Two-Way Separated Twist |
| Feature: |
Easily Assembled |
| Color: |
Primary Colors |
| Certification: |
ISO9001 |
| Packing: |
Pallet |
Product Description
Crimped Wire Mesh can be also known as the iron crimped mesh, stainless steel crimped mesh, black iron crimped mesh according to different materials.
Crimped Wire Mesh is made in a variety of materials through crimping mesh machine, a kind of universal wire products with square or rectangular openings.
Crimped Wire Mesh Material: Iron wire, black wire, stainless steel wire, copper wire and other non-ferrous metal.
Weaving: Pre-crimping before Weaving. In two-way separated wave bending, locked bending, flat-topped curved, two-way bending, one-way separated wave bending.
Features: Structure firm and durable.
Uses: Used for mining, coal plants, construction, petrochemical industry, construction machinery, etc.
Crimped Wire Mesh common specifications:
Diameter 1.0mm x mesh opening 8mm or 10mm
Diameter 1.5mm x mesh opening 12.5mm, 15mm or 20mm
Diameter 3mm x mesh opening 15mm, 20mm, 30mm
Length and width specifications: 1mX25m 1mX30m 1.2mX25m 1.2mX30m
Wire Gauge
SWG
| Wire Diameter
mm
| Mesh/Inch | Aperture
mm
| Weight
kg/m 2
|
| 14 | 2.0 | 21 | 1 | 4.2 |
| 8 | 4.05 | 18 | 1 | 15 |
| 25 | 0.50 | 20 | 0.61 | 2.6 |
| 23 | 0.61 | 18 | 0.8 | 3.4 |
| 24 | 0.55 | 16 | 0.1 | 2.5 |
| 24 | 0.55 | 14 | 0.12 | 4 |
| 22 | 0.71 | 12 | 0.14 | 2.94 |
| 19 | 1 | 2.3 | 0.18 | 1.45 |
| 6 | 4.8 | 1.2 | 2 | 20 |
| 6 | 4.8 | 1 | 2 | 20 |
| 6 | 4.8 | 0.7 | 3 | 14 |
| 14 | 2.0 | 5.08 | 0.3 | 12 |
| 14 | 2.0 | 2.1 | 1 | 2.5 |
| 14 | 2.0 | 3.6 | 1.5 | 1.9 |
Anping County Xinlu Wire Mesh Products Co., Ltd, . Is located in Anping county which well known of "The hometown of wire mesh in China", emerged from Anping mine screen mesh factory in 1994 with a founding of 1.5 million RMB. It has a comparatively long history, a large scale production rate, and it is the only company among others in the same profession to have been certified by the IS09001 quality system authentication.
Our company produce and sell as following: Johnson specialty screens, Water well screen, Wedge wire screen, Wedge wire slot tube, Wire wrap screens, Strainer pipe, Spiral screen tube, Rod based continuous slot screen pipe, Wire-wrap screen pipe, Mine screen mesh, Screen cylinders, Oil screen tube, Drilling well screen, Reverse rolled screen tube, V-ee wire screen, screen cylinders, sand control well screen, water filter, screen nozzle, water & gas strainer, filter element, stainless steel screen, low carbon steel screens, welded wedge wire screens, screen filter, rotary filter, various kinds of ore screen meshes, sieve bend, arc screen, wire wrapped panel, flat wedge wire panel, vibrating sieve screen plate, wire wrapped liner, johnson scren plate, continuous slot screens, Gabions, chain link fence, fence netting, welded wire mesh, stainless stell wire mesh, Galvanized wire, Galvanized wire mesh, crimped wire mesh and wire mesh, Mesh belt conveyor, Window Screening Series, Metal jewelry products and so on. The products are used in drilling well / pump, the trades, such as ore choosing, petroleum, chemical industry, electron, transportation, plastics, food, architecture, traffic, Musical Instruments, safety, etc. Our products can be seen everywhere in China, as well as African countries, Middle East and the regions of Southeast Asia.
