| Price: | US $ 8000-100000set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1set |
| Pay Type: | T/T |
Our main product is industrial boilers such as steam boiler, hot water boiler and thermal oil heater (boiler) for different manufactures.
Fuels: All kind of coal and biomass pellet, wood, sawdust, stalk, rice hull, bagasse coconut shell, hemp palm shell etc biomass fuels.
Features:
1. The operation relize automatically, reduce the worker operate labour intensity.
2. Higher thermal efficiency;
3. It is a package boiler, just install the parts are valve gauge, tube, forced draft fan, induced draft fan, smoke tube, dust collector and water electric system that can start to use. also has fire off tool that the burning safely.
4. It is easy to transportation and install, lower capital investment.
Company Informations:
Supply high quality high efficiency Boiler.
1. Class B boiler manufacture, capacity around 200 sets per year.
2. Each boiler system pars is from first class brand all over the world or China.
3. Strict quality control system, from the drawing design, materials, welding,
water testing, pressure testing to finish shipment.
4. Service: Suport technical supervision.
| Model | DZL2-1.25-M | DZL4-1.25-M | DZL4-1.6-M | DZL6-1.25-M | DZL6-1.6-M | ||
| Rated evaporation (t/h) | 2 | 4 | 4 | 6 | 6 | ||
| Rated operating pressure (MPa) | 1.25 | 1.25 | 1.6 | 1.25 | 1.6 | ||
| Rated Steam Temperature (°C) | 193 | 193 | 204 | 193 | 204 | ||
| Feed Water Temperature (°C) | 20 | 20 | 20 | 20 | 20 | ||
| Design efficiency(%) | ≥80% | ||||||
| Whole size (M) | L | 5.4 | 6.2 | 6.45 | 7.54 | 7.5 | |
| W | 2.2 | 2.7 | 2.8 | 2.8 | 2.8 | ||
| H | 3.3 | 3.65 | 3.65 | 3.65 | 3.655 | ||
| Boiler body weight (T) | 23 | 27 | 31 | 33 | 33.6 | ||
| Prod Model: | DZL3-1.25-T |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Steam Capacity: | 3tons/Hr |
| Steam Pressure: | 1.25MPa |
| Steam Temperature: | 193 |
| Thermal Efficiency: | 75% |
| Available Fuel: | All Kind of Coal, Logs, Wood Chip, Nut Shell etc |
| Consumption: | 440kg/Hr (Hv=5500kcal/Hr) |
| Main Power Source: | 3p/220~480V/50~60Hz |
| Delivery Time: | 25~60 Days |
| After-Sale Service Provided: | Engineers Available to Overseas |
| Function: | Steam Boilers |
| Fuel: | Coal-Fired |
| Usage: | Industrial |
| Pressure: | Low Pressure |
| Burning Style: | Chamber Combustion Boiler |
| Drum Placement: | Horizontal Boiler |
| Media: | Steam and Water |
| Installation: | Packaged Boiler |
| Water Circulation: | Natural Circulation |
| Manufacturing Level: | B |
| Structure: | Water-Fire Tube |
