Hangzhou Xiaoshan Dunben Magnet Co., Ltd. >> Arc Strong Permanent Neodymium Magnet

Arc Strong Permanent Neodymium Magnet

Name: Arc Strong Permanent Neodymium Magnet
Brand: China-Manufacturer-Directory.com
SKU: 765274105
Availability: InStock
Rating: 4.6 (64 reviews)

Supplier:	Hangzhou Xiaoshan Dunben Magnet Co., Ltd.
Price:	US $ 0.5-0.8/Piece
Min Order:	300/Piece
Quantity::
Trade Terms:	FOB,DAP,EXW

Product Specifications

Prod Model:	N40
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Tolerance:	Customized
Application:	Motor Magnet
Coating:	Nickel
Grade:	N40
Shape:	Arc

Product Description

Neodymium Permanent Magnet

The third generation of rare earth-permanent magnetic NdFeB is the strongest performance of permanent magnetic in the contemporyera.It's process a high potential magnetic properties,can be easy to be cutting and drilling,so as processing of complex shape.

Attributes of Neodymium Magnet

NdFeB magnet has very high resistance to demagnetization
NdFeB magnet has high energy for size
NdFeB magnet is good in ambient temperature
NdFeB magnet has moderately priced

Grade of Neodymium Magnet

Grade	Max. Energy Product		Remanence		Coercive Force				Rev. Temp. Coeff.		Curie Temp.	Working Temp.
	(BH)max		Br		Hc		Hci		Bd	Hd	Tc	Tw
	MGOe	kJ/m3	kG	mT	kOe	kA/m	kOe	kA/m	%/oC	%/oC	oC	oC
N35	33-36	263-287	11.70-12.10	1170-1210	>10.9	>868	>12	>955	-0.12	-0.6	310	80
N38	36-39	287-310	12.10-12.50	1210-1250	>11.3	>899	>12	>955	-0.12	-0.6	310	80
N40	38-41	302-326	12.50-12.80	1250-1280	>11.6	>923	>12	>955	-0.12	-0.6	310	80
N42	40-43	318-342	12.80-1320	1280-1320	>11.6	>923	>12	>955	-0.12	-0.6	310	80
N45	43-46	342-366	13.20-13.80	1320-1380	>11.0	>876	>12	>955	-0.12	-0.6	310	80
N48	46-49	366-390	13.80-14.20	1380-1420	>10.5	>835	>11	>876	-0.12	-0.6	310	80
N50	47-51	347-406	13.9-14.3	1390-1430	>10.5	>836	>11	>876	-0.12	-0.6	310	80
N30M	28-32	223-255	10.90-11.70	1090-1170	>10.2	>812	>14	>1114	-0.12	-0.59	320	100
N33M	31-35	247-279	11.40-12.20	1140-1220	>10.7	>851	>14	>1114	-0.12	-0.59	320	100
N35M	33-37	263-294	11.80-12.50	1180-1250	>11.0	>875	>14	>1114	-0.12	-0.59	320	100
N38M	36-40	286-318	12.30-13.00	1230-1300	>11.5	>915	>14	>1114	-0.12	-0.59	320	100
N40M	38-42	302-334	12.60-13.20	1260-1320	>11.8	>939	>14	>1114	-0.12	-0.59	320	100
N42M	40-44	318-350	13.00-13.50	1300-1350	>12.0	>955	>14	>1114	-0.12	-0.59	320	100
N45M	42-46	334-366	13.20-13.80	1320-1380	>12.2	>971	>14	>1114	-0.12	-0.59	320	100
N33H	31-34	247-271	11.30-11.70	1130-1170	>10.5	>836	>17	>1353	-0.11	-0.58	320-350	120
N35H	33-36	263-287	11.70-12.10	1170-1210	>10.9	>868	>17	>1353	-0.11	-0.58	320-350	120
N38H	36-39	287-310	12.10-12.50	1210-1250	>11.3	>899	>17	>1353	-0.11	-0.58	320-350	120
N40H	38-41	302-326	12.40-12.80	1240-1280	>11.6	>923	>17	>1353	-0.11	-0.58	320-350	120
N42H	40-43	318-342	12.80-13.20	1280-1320	>12.0	>955	>17	>1360	-0.11	-0.58	320-350	120
N33SH	31-34	247-272	11.30-11.70	1130-1170	>10.6	>844	>20	>1592	-0.11	-0.55	340-360	150
N35SH	33-36	263-287	11.70-12.10	1170-1210	>11.0	>876	>20	>1592	-0.11	-0.55	340-360	150
N38SH	36-39	287-310	12.10-12.50	1210-1250	>11.4	>907	>20	>1592	-0.11	-0.55	340-360	150
N40SH	38-41	302-326	12.10-12.80	1240-1280	>11.8	>939	>20	>1592	-0.11	-0.55	340-360	150
N28UH	26-29	207-231	10.20-10.80	1020-1080	>9.6	>768	>25	>1990	-0.11	-0.51	350-380	180
N30UH	28-31	223-247	10.80-11.30	1080-1130	>10.2	>816	>25	>1990	-0.11	-0.51	350-380	180
N33UH	31-34	247-271	11.30-11.70	1130-1170	>10.7	>856	>25	>1990	-0.11	-0.51	350-380	180
N28EH	26-29	211-236	10.40-10.90	1040-1090	>9.8	>784	>30	>2388	-0.11	-0.51	350-380	200

Shape of Neodymium Magnet

Disc, Cylinder, Block, Ring, Countersunk, Segment, Trapezoid, Irregular shapes and more. Customized Design (Design proper magnets for clients specific requirements)

Coating of Neodymium magnet

Ni-Cu-Ni, Nickel, Zn, Gold, Silver, Copper, Epoxy, Chemical, PTFE, Parylene, Everlube, Passivation and more.
Directions of Magnetization

a.Axially Magnetized

b. Diametrally Magnetized

c. Radial Magnetized

Package details of Neodymium Magnet

Our delivery time

1. 10-12 days for sample

2. 15-20 days for mass quantity

As the manufacturer of magnet material and magnetic assembly, Dunben Magnet Co., Ltd has developed magnet and precision magnetic production for the worldwide automotive, electronics, panel meter, power industries for ten years.

Our company was established in the year of 2004, after long delveoping, our manufactures products which serve global markets and include a broad range of magnetic materials and components, magnetic lift systems, material handling equipment, , magnetic motor, bonded magnets, and assemblies.

Customer can count on our excellent work system, professional engineer team, responsible sale team, excellent produce team, strict QC team and perfect after-sale service from Dunben magnet co. Ltd.

In order to satisfy our customer's needs, Hangzhou Dunben focuses on quality control with continuous improvements on all manufacturing processes and provides the most competitive prices based on domestic resources. Customized magnets are always available here.

Depend on high technical, strict quality system, competitive price, our business have been exported to over 10 countries, such as USA, Korea, Germany and so on

We are sincerely willing to establish long business relationships with all customers, so welcome all friend come to visit our factory
