Audio Conference Processor (DSP9600)

Name: Audio Conference Processor (DSP9600)
Brand: China-Manufacturer-Directory.com
SKU: 707885685
Availability: InStock
Rating: 4.6 (116 reviews)

Supplier:	Huiming Electronic Technology Co., Ltd.
Price:	Negotiable/Set
Min Order:	50/Set
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	DSP9600
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Online edition
Touch Screen:	Without Touch Screen
Monitor:	LCD
Application:	Commercial

Product Description

Features:
1. 3.2`` 65.5K-pixel color LCD screen of the processor.
2. English & Chinese are optional for this processor.
3. With AES digital audio input support.
3. 255MHz, 96kHz sampling rate, 24 bit AD/DA convertor. 32 bit DSP processor;
4. PC to control. Provide USB prot for the prcoessor.
5. The processor front panel is with manual some bottons to operate.
6. Center, SUB and SUR are of 5 bands PEQ, X-OVER, mixer, polarity, delay, limiter and gain to set.
7. 21 memory functions, of 10 preset & 10 ' self eff, all parameters to AUTO save
8. Each input of this processor has H/L cut, 7 bands EQ.
9. Processor output channel has 4 balance & unbalance, can be flexible with the power op-AMP (When the MIC into the output, Auto-cut disco & songing. Signal AUTO attenuation, proportion is adjustable)
10. Each input & output of the processor has freq, 6 band EQ, limiter, sound chose, Mix rate gain delay etc. K field applicable.

Technical Parameter
Items	Parameter			Test
Output channel	main output(L/R)		√
	Center		√
	SUB		√
	Surround L/R		√
(dB)S/N	MIC		85dB	1KHz OdB input
	MUSIC		100dB
THD	MIC		0.01%	1KHz OdB
	MUSIC		0.01%	input
MAX Input Level	MIC		250mv	1KHz
	MUSIC		6V	input
MAX Input Level	MIC		10Vrms	1KHz
	MUSIC		10Vrms	input
Sensitivity	MIC		15mV
	MUSIC		300mv
(Ω )	MIC		10K unbalance
Input impedance	MUSIC		47K unbalance
(Ω ) Output impedance	300 balance, 1K unbalance
Channel resolution	85dB
Feed back inhibition	4 level F. B
Display Screen	3.2``65.5K-pixel color LCD display
Processor	255MHz, 96KHz sampling rate, 24 bit AD/DA conversion. 32 bit DSP chip processor;
Channel Parameter	MIC Input	7 Band PEQ+LPF+HPF, FREQ: 20Hz-20000Hz 239 Total: 239 point Band width: 0.05oct-3oct, step : 0.05oct Gain: ± 20dB
	MUSIC Input	7 Band PEQ+LPF+HPF, FREQ: 20Hz-20000Hz Total: 239 point Band width: 0.05oct-3oct, step : 0.05oct Gain: ± 20dB
	L/R Main output	Mix+Polar+15 Band PEQ+LPF+HPF+Limiter+Delay+Gain
	Center	Mix+Polar+5 Band PEQ+LPF+HPF+Limiter+Delay+Gain
	SUB	Mix+Polar+5 Band PEQ+LPF+HPF+Limiter+Delay+Gain+
	Surround	Mix+Polar+5 Band PEQ+LPF+HPF+Limiter+Delay+Gain
Weight	NET Weight		4.6KG
	Total Weight		5.0KG
Dimensions(WHD)	Unit Dimensions		48223466MM
	Pack Dimensions		534306126MM

Since 1999 Huimig Electronic Technology Co., Ltd. Has been manufacturing DSP processor professional audio & karaoke system. In digital audio DSP treatment effect has development & production experience & many variety of DSP audio solutions. Our team has committde itself to the development & production with every possible effort toward top quality, customer satisfaction, quick delivery & good service.

HM adopts production management systems & advanced production technologies. We're the best OEM/ODM business partner.
