Product Specifications
| Prod Model: |
HCC6032 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Light Source: |
95mm×70mm×160mm |
| Scan Width: |
220mmscanner Window, 220mm200mm |
| Support Interface: |
RS232, PS/2 Keyboard, USB |
| Size: |
95mm×70mm×160mm |
| Type: |
Data Collector |
| Certification: |
CE & FCC Doc Compliance |
Product Description
Feature
Full independent intellectual property rights (multiple national patents)
Very comfortable operation sense
Intelligent AGC control
Rich decoding types
Service life of button reaches up to 50 million times
Full quakeproof and antiknock design
Suiting with each kind of charge machine
Compatible with the output of keyboards in more than 20 different countries
Specification
Performance
Light Source 650nm visible laser diode
Scan Pattern Mongline scan
Scan Rate 100± 2 times/ sec.
Scan Precision 0.10mm (pcs0.9)
Scan Width 220mmscanner window, 220mm200mm
Scan Depth of Field 0-250mm (0.33mm. PCS 90%)
Corner 30°
Elevation 65°
Deflection 55°
Decode Capacity EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, and so on
Support Interface RS232, PS/2 keyboard, USB
Print Contrast 30%UPC/EAN 100%
Bit Error Rate 1/5 million
Mention Pattern Buzzer, indicator
Scan Module Manual, automatism (stand)
Physics
Size 95mm× 70mm× 160mm
Weight 150g
Material ABS+PC
Cable Standard 2.5m
Electricity
Voltage 5V
Working Current 100mA
Sleep Mode Current 1mA
Laser Safety Comply with national Laser II safety standard
EMC CE & FCC DOC compliance
Environment
Working Temperature 0degree centigrade-45degree centigrade
Storage Temperature -20degree centigrade-60degree centigrade
Humidity 5%-95% non-condensing
Light Levels Max. 5, 000 Lux (Fluorescence)
Shock Designed to withstand 1.5m drops
| Performance |
| Light Source | 650nm visible laser diode |
| Scan Pattern | Mongline scan |
| Scan Rate | 100± 2 times/ sec. |
| Scan Precision | 0.10mm (pcs0.9) |
| Scan Width | 220mm@scanner window, 220mm@200mm |
| Scan Depth of Field | 0-250mm (0.33mm. PCS 90%) |
| Corner | 30° |
| Elevation | 65° |
| Deflection | 55° |
| Decode Capacity | EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, and so on |
| Support Interface | RS232, PS/2 keyboard, USB |
| Print Contrast | 30%UPC/EAN 100% |
| Bit Error Rate | 1/5 million |
| Mention Pattern | Buzzer, indicator |
| Scan Module | Manual, automatism (stand) |
| Physics |
| Size | 95mm× 70mm× 160mm |
| weight | 150g |
| Material | ABS+PC |
| Cable Standard | 2.5m |
| Electricity |
| Voltage | 5V |
| Working Current | 100mA |
| Sleep Mode Current | 1mA |
| Laser Safety | Comply with national Laser II safety standard |
| EMC | CE & FCC DOC compliance |
| Environment |
| Working Temperature | 0º C-45º C |
| Storage Temperature | -20º C-60º C |
| Humidity | 5%-95% non-condensing |
| Light Levels | Max. 5, 000 Lux (Fluorescence) |
| Shock | Designed to withstand 1.5m drops |
