Product Specifications
| Prod Model: |
water filling line |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Stainless Steel |
| Shipment Terms: |
by Sea or by Train |
| Certification: |
CE, ISO |
| Delivery Time: |
40days After Payment |
Product Description
Big Bottle Water Bottling Line
I)The main purpose and characteristics
The filling machine is suitable for 5L pure water, mineral water and other non-automatic liquid filling gas, its main features are:
1 bottle red card is the bottleneck parts of method used, rotate 180 degrees, washing efficiency.
2, the use of fixed surface of the filling means filling quality, filling speed quickly.
3, the use of mechanical liquid level automatic control mechanism.
4, filling valve, hydraulic cylinder and other parts of surface are in direct contact with high-quality stainless steel, corrosion-resistant, easy to clean, in line with industrial hygiene requirements.
5, the use of electromagnetic speed control motor, strong production capacity to achieve any adjustments.
6, compact structure, convenient operation and easy maintenance.
II)Working principle:
The machine adopts the principle is given liquid filling pressure filling. Main process is: Cleaned the bottle into the bottle track wheel appropriated by the lift shaft parts, with the dial clockwise, the bottle filling valve from the bottom up and seal the bottle and realized the bottle sealed contact with the valve open Liquid cylinder of liquid in the downstream effects of its weight into the bottle, while the air inside the bottle of liquid in the shed, driven out from the center tube discharge valve, the liquid until the bottle vent pipe flooded the center, the irrigation Installed to stop, with the bottle down, filling valve closed, filling the bottle by the end of the bottle sealed track wheel output into the next process.
III)Main technical parameters:
Rinse heads: 8
Filling heads: 8
Capping heads: 4
Rated capacity: 600~800 bottles / hour (5 liters bottle)
Filling capacity: 5L(standard filling volume)
Filling materials: Water
Bottle type: PET bottle, bottle diameter 100-220MM, bottle height 150-350MM (special requirements can be customized)
Filling method: Filling pressure
Applicable cap type: Standard plastic screw cap
Power: 2.2KW
Voltage: 220V three-phase AC
Rinse water consumption: (sterile water) 0.5-0.8M3 / H
Pressure: 0.4MPA
Equipment Dimensions: L2780 * W1965 * H2100MM
Equipment weight: 4000KG
Beverage| Model | RFCC16-16-5 | RFCC24-24-8 | RFCC32-32-8 | RFCC40-40-10 |
| Washing,-Filling-Capping | 16-16-5 | 24-24-8 | 32-32-8 | 40-40-10 |
Producing capacity
(600ml) | 8000
(bph) | 10000
(bph) | 12000
(bph) | 15000
(bph) |
| Suitable bottle size(mm) | φ=50-108 H=170-340 330ml-2.25L |
| Pressure (kg/cm²) | 2~3 |
| Outside vacuum pump power (kw) | Main motor
3.12kw | Main motor
3.92kw | Main motor
3.92kw | Main motor
5.87kw |
Overall dimension (mm)
(LxWxH) | 2760*2060*2700 | 2800*2230*2700 | 3550*2650*2700 | 4700*3320*2700 |
