Carbonated beverage filling Machine
Carbonated beverage filling Machine combines rinsing bottles, filling bottles and capping bottles together with PLC control. It is mainly used for plastic bottles with carbonated beverages and non-carbonated beverages.
Characteristic of machine
All parts contacting with beverages adopt top grade stainless steels whose surfaces are polished till smooth for easy rinsing. The sealing materials are EPDM rubber.
Carbonated beverage filling line/carbonated drink machine/carbonated filling machine/carbonated beverage machinery/carbonated filling line
Adopt PLC as center control, make use of pressure transmitter and electromagnetism pneumatic valve to measure liquid level, keep balance of filling pressure to insure stable liquid level.
Adopt new type filling valves which are especially designed for plastic bottles. The returned air and the liquid in filling tank are insulated to insure cleanliness of the filled beverages.
Adopt advanced magnet clutches for capping with adjustable torsional moment to insure capping safely and reliably.
The composition of equipment:
__. Washing part
__. Filling part
__. Capping part
__. Pneumatic part
__. Electricity part
__. Electricity box part
__. Main transmission part
__. Chain box and turnover arc board part
Welcome to contact us about our Carbonated Washing Filling Capping Machine.
Main Technical Specifications
Model: | RFCC14-12-5 | RFCC16-16-5 | RFCC24-24-8 | RFCC32-32-8 | RFCC40-40-10 |
Capacity :600ml | 3000 | 5000 | 8000 | 12000 | 15000 |
Bottle shape: | Round or square (Bottle Diameter):φ50-.φ110mm (Height):150-340mm PE screw cap ≤±5mm |
Size of PET bottle: (mm) |
Cap: |
Filling precision: |
Main Power (KW) | 3 | 4.5 | 6 | 7.5 | 11 |
Overall size:(mm) | 2000*1600*2300 | 2450*1800 *2350 | 2780*2200 *2350 | 3600*2650 *2350 | 3800*2950 *2400 |
Weight: (kg) | 2800 | 3500 | 4500 | 5500 | 6500 |
Established in 2002, Blissum is one of the professional & reliable China manufacturers & provide of liquid & semi-liquid filling machinery, sealing capping machinery & other liquid packaging machinery with reliable machine quality & after sale service!
Our extensive experience of liquid & semi-liquid filling & packaging and container handling enables us to offer complete solutions to designs, manufactures, supplies, installs, maintains, troubleshoots, and upgrades plants for complete processing and packaging lines with special emphasis on bottling in glass, PET, Jar, can, and kinds of container
With a flexible approach, we are able to provide the right solutions for a diverse customer base, from small start up companies through to major national companies. Our many satisfied customers come from a very wide range of industries, including toiletries, cosmetics, pharmaceuticals, food, drink, household products and chemicals.
Blissum with ethos focus on after sale customer service, strive to achieve excellence, from our initial response to your enquiry to our after sales support and spares service.
