Product Specifications
| Prod Model: |
CH150(A) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Blending Machine |
| Model: |
CH150(a) |
| Trough Capacity: |
150 L |
| Miaing Arm Speed: |
24r/Min |
| Main Motor: |
3kw |
| Certification: |
ISO |
| Finished Dosage Form: |
Powder & Granule |
Product Description
Main Application:
As a whole stainless horizontal tank type mixer (blender), this CH150(A) Blending machine is widely used for mixing of powdery or paste material in pharmaceutical chemical and foodstuff industries.
Working Principle:
S type agitiating paddle is rotated, through mechanical driving, which pushes the material turn repeatedly and mix uniformly. Operate with electrical control, CH150(A) Blending machine can set mixing time to realize automatic stop and electric discharge upon expiration, thus improving the mix quality of each batch of material and realizing the high homogeneous mixing.
|
ITEM |
TYPE |
|
CH10(A) |
CH50(A) |
CH100(A) |
CH150(A) |
CH200(A) |
Trough capacity
L |
10 |
50 |
100 |
150 |
200 |
Miaing arm speed
r/min |
25 |
24 |
24 |
24 |
24 |
|
tilting angle of the trough |
105 |
105 |
105 |
105 |
105 |
Main motor
KW |
0.37 |
1.5 |
2.2 |
3 |
3 |
tilting motor
KW |
by hand |
|
|
|
|
overall dimension
mm |
550*250*540 |
1200*520*1000 |
1480*685*1125 |
1480*685*1125 |
1660*600*1190 |
weight
kg |
65 |
200 |
350 |
850 |
850 |
