Product Specifications
| Prod Model: |
TCR-610 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Card Material: |
Paper and PVC/ Mylar Cards |
| Weight: |
Net of Card Collector About 0.7kg |
| Control Interface: |
RS232//I.O |
| Commodity: |
Card Collector |
| Voltage: |
24VDC |
| Operating Temperature: |
-30°c-85°c |
| Used Condition: |
Install in Bin |
| Install In Bin: |
2s |
| Brand: |
Tenet |
| Warranty: |
1 Year |
| Certification: |
CE |
| Type: |
Card Collector |
Product Description
Automatic Card Collector for Parking System Machine
Parking Lot IC Card Collector/ card receiver machine TCR-610
Specification
Industrial design, good resistance to abrasion and corrosion,fit for high and low temperature environments
Directly connect to the inductance signal to achievement cards' collection when car is coming
Provide RS232/RS485 or I / O voltage two control interfaces
Die-wide production ensure the products' quality and consistency
Features:
Operating voltage:24VDC(Max current 2A,static current0.1A)
Operating temperature: -30°C-85°C
Operating relative humidity: 30—90%
Used condition: install in bin
Card collecting speed: about 2s
Card material:paper or polyester cards
|
www.chinatenet.com |
24VDC (max current 2A, static current 0.1A) |
|
Operating temperature |
-20 to 85 |
|
Operating humidity |
30-90% |
|
Use condition |
install in bin |
|
Card available |
width: 54+/-0.5mm Length: 85+/-0.5mm |
|
Thickness |
0.3-2.5mm (adjustable) |
|
Card material |
Paper or Polyester card |
|
Net weight |
2.0kg (including the briquette) |
|
Time of issuing |
max0.5s |
|
Capacity of stacker |
50pcs (0.8mm), 100pcs available when an extra stacker is needed. |
Shenzhen Tenet Technology Co., Ltd. is a professional intelligent parking equipments manufacturer. Our company has a high-quality and professional R&D team which focused on designing and developing parking equipments over 10 years. We can provide stable and reliable equipments and good services for many system integrators and contractors.
Company"s main products: TCD series automatic card dispenser, TLD series loop detector, TCR series card collector (Ticket Checking Machine Core), parking guidance system, LED display screen, UHF remote card readers, intelligent control motherboard, and so on. The products are widely used in intelligent parking system, highway automatic toll station system, road and bridge toll station system, electronic police system, automatic ticket vending system, Intelligent card Vending System, tourist attractions and show ticket system.
We firmly believe that we will bring the greatest potential development and maximum profits for our customers. We will do our innovation for customers, development demands, do our technology research and product developing for customers' profits.
