Automatic Cylinder Cross-Cut Cutter Machine

Product Specifications

Prod Model:	YD-420
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Die Cutting Machine Size:	2500*1200*1750mm
Mold:	All Kinds Mold Is Available
Die Cutting Area:	450*420mm
Max Speed:	15000piece/Hours
Weight:	2500kg
Package:	Wooden Box
Pressure:	1-8t
Max Feedstock Width:	4500mm
Power:	220V/380V/420V
Suitable Knife:	Hardware
Imprinting Type:	Platen
Placing Form Of Template:	Horizontal
Die Cutting Tool:	Metal Mold
Automatic Grade:	Automatic
Application:	Mobile Phone Accessories

Product Description

Automatic Cylinder Cross-cut Cutter Machine
Standard function:
Feeding→Die Cutting→ Exhaust→Rolling/Cutting Forming

Cutter Machine Features:
1. Apply to the die cutting of PET/PVC/PE film (protectors of mobile phone/computer and touch screen protective film etc)
2.Adopt servo motor to pull materialconvey material, which can make full or half cutting,  exhaust ,high-precision,lower noise,high speed.
3. Adopt all-in-one automatic induct feeding system to prevent the material from being damaged and no second pollution.
4. The fan device can ensure not to damage the material, add tension of material, avoid shifting direction of material, and keep good effect.
5. According to customer requirement which can work with labelling machine together to ensure the efficiency of unloading.

Applications:
PET/PVC/PE film ,protectors of mobile phone/computer and touch screen protective film etc.


Cutter Machine Detail:

Specification:

Model	YD230DB	YD280DB	YD350DB	YD420DB
Max Width	240	300	370	440
Template Area	240*220	300*250	370*320	440*370
Cutting Speed	1800-12000	1800-12000	1800-12000	1800-10800
Voltage(V)	AC380V/220V	AC380V/220V	AC380V/220V	AC380V/220V
Main Motor Power(KG)	2.2KW	3KW	4KW	4.8KW
Dimension(MM)	2400*1100*1750	2500*1200*1750	2800*1250*1800	3100*1300*1800
Net Weight(KG)	1200KG	1700KG	1900KG	2300KG
