Product Specifications
Prod Model: |
SP-660 |
Markets: |
Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia |
Dimension(L*W*H): |
3550*1330*2350mm |
Voltage: |
380V/50Hz |
Weight: |
4000kw |
Power(W): |
45kw |
Warranty: |
1 Year |
Control Method: |
PLC |
Product Description
Packaging & Delivery
Packaging Details: | Standard export wooden case |
---|
Delivery Detail: | Within 35 days after receive the deposit |
---|
I. Main Technical Parameter
1. Power Supply | 380V/3P/50HZ |
2. Material | PP/PS/PET/PVC plastic thermoforming sheet |
3. Driving Method | Cam + Air cylinder |
4. Forming Speed | around 35cycles/min (forming depth 130mm) |
5. Sheet Width | W=660mm (adjustable) |
6. Air Pressure | 0.6~0.8Mpa |
7. Air Consumption | 2200L/min |
8. Air Compressor Exhausting Capacity | 2200~3000L/min |
9. Water Consuption | around 0.5m3 |
10. Machine Dimension | 3.3×1.4×2.2m |
11. Electrical Consumption | Approx. 45KW |
12. Max. Forming Area | 650*320mm |
13. Max. Forming Height | 130mm |
14. Pillars | 4 |
II. Finished Product Samples
III. Mould Sampleas
Contact person: Eudora
Address: Doubei Industry, Pingyang County, Wenzhou City,
Zhejiang Province, China
Postal Code: 325400
Tel:0086-0577-63790922
Fax:0086-0577-63790122
Mob:0086-13616824588
Website: //www.cn-sinoplast.com/
Ruian Sinoplast Machinery Co., Ltd is a professional manufacturer of Plastic Sheet Extrusion Lines, Thermoforming Machines&Auxiliary Equipments from China.
Our company has a professional technician team with rich experience on the R&D of plastic sheet extrusion lines, thermoforming equipments and forming molds for many years. We could provide our clients complete service from machines and molds design, manufacture, installation, debugging and workers training.
We have passed the ISO9001: 2000 Quality Management System and CE certificate. With the market as our guide and continuous creation and renovation, we have won the honor and good image in the packaging industry and relative industry with high quality and good service. Our products are well sold throughout the country and exported to many different countries, such as, Southeast Asia, Russia, Europe, Middle East, Africa, America and etc.
Our company welcomes all the clients to visit our factory for the future communication and cooperation.
